Pipe Thread Lathe Low Price for Inner Tube Processing Thread

Name: Pipe Thread Lathe Low Price for Inner Tube Processing Thread
Brand: HaiShu
SKU: 128528505

US$ 10,000 - 18,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Taian Haishu Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Pipe thread lathe Qing Dao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 610mm

Place of Origin Shandong, China

Brand Name HaiShu

Model Number CKG130A

Voltage 220V/380V

Power(W) 7.5kw

Dimension(L*W*H) 2650*1450*1700

Weight 2800kg

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

CNC pipe thread lathe specification

Item	Unit	specification
Item	Unit	CKG130A	CKG160A
Max swing diameter	mm	610	625
Maximum turning length	mm	1000
Maximum processing outside diameter of pipe	mm	135	157
Spindle bore	mm	140	160
Number of spindle speeds	Servo stepless speed change, 10~800rpm
×/Z Servo motor torque	N.m	4/6
Chuck form	Three-jaw chuck φ400mm
Turret form	Four-station ,Vertical
×/Z Rapid traverse	m/min	4/4
Tailstock quill diameter	mm	75
Tailstock quill stroke	mm	150
Tailstock sleeve taper	MT5
Spindle center to the height of the rail	mm	305	320
Main motor	7.5KW(Servo motor),0-3000rpm
Rail width	mm	390	490
Machine weight	Kg	2600	3200
Machine outline size (L × W× H)	mm	265014501700	2650×1550×1700
CNC system	mm	KND100Ti/GSK980TA/Siemens/Fanuc(Optional)
