RUIAO TEZ25 plastic chain link drag for wire protection
wire track |
Outside diameter |
Bending radius |
Pitch |
Type |
|
TEZ25*25 |
40.6 |
45 |
55/75/100125/150 |
44 |
Top cover and bottom cover could be open bridge/en-closed type |
TEZ25*38 |
40.6 |
58 |
|||
TEZ25*50 |
40.6 |
70 |
|||
TEZ25*57 |
40.6 |
77 |
|||
TEZ25*75 |
40.6 |
95 |
|||
TEZ25*103 |
40.6 |
123 |
|||
TEZ25*125 |
40.6 |
145 |
|||
Guide for type selection of RUIAO cnc plastic chain link drag for automation
1.Material: steel chain link drag , stainless steel chain link drag , nylon chain link drag.
2.Function: single row type, compound rows type, enclosed type,anti-noise type, S-type
3.Environment:oil/rain/salt/humidity/rubbish/high-TEMP/low-TEMP/load-bearing/long travel range/low noise~
4.Assembly: Unitary type,bridge type, semi enclosed type,total enclosed type.
5.RUIAO size: TP/TEZ/TLZ/TLJ/TLC/TL/TLG/JR-2/DGT
Brief introduction of RUIAO cnc plastic chain link drag
1. The wire track is assembled by single unit, each unit can be disassembled easily by the flat screwdriver, welcome ask us for installation video!
2. For the same series,
they have the same'height'and pitch, while the width and bending radius can be difference,
you can choose the most suitable one according to our parameter list below,
or ask us to help you choose the right one at any time~
3. Above TEZ35*50 size,in order to manage your moving wires and tubes,you can add separators.
4. When the length of the cable chain is more than 7meters per piece, pls add support roller or guide bridge
some model specification can be offered, according to your requirement ,some datas can be different
any accessory should be carefully checked before assemble,any finished products should be perfect before packed
