Help CenterFull Precision Converse and Positive Roller Coater
Related Products
-
Full Precision Double Roller CoaterUS$ 10,000 - 20,000MOQ: 1 Set -
Full Precision Single Roller CoaterUS$ 7,000 - 10,000MOQ: 1 Set
-
UV Coating Line/Machine/MDF Varnish Roller Coater For UV/MDF/Wood/FurnitureUS$ 11,000 - 14,000MOQ: 1 Set
-
Best Quality uv Drying Curing MachineUS$ 10,000 - 13,000MOQ: 1 Set
-
Full Precision Single/Double/Converse and Positive Roller Coating Machine for UV PENegotiableMOQ: 1 Set
Machine Configuration
1, using imported materials rubber roller rubber roller diameter of 240mm, the roll surface by CNC precision machining.
2, rolls with a diameter of 150mm light big roll, chrome roll surface, cylindrical grinder by CNC precision machining.
3, equipped with imported materials scraper strong toughness, by the reducer adjustment, high accuracy.
4, the conveyor belt is 3mm slip, solvent resistance, to prevent the phenomenon from the floor, plus anti-deviation device.
5, running light roller and rubber roller by an independent drive and control gear, wherein the spacing between the adjustment screw through a worm machine, driven dovetail mechanism to complete.
6, the bearing sealing structure to prevent the penetration of paint.
7, the entire machine configuration Taiwan Delta converter and three-phase asynchronous motor worm gear.
8, the whole package, a diaphragm pump, a heating oil tank 20L.
Customers need to take care of themselves with others:
1,50Hz, 380V three-phase power supply.
2,0.5MPA gas source.
Modle |
JXRA Ⅲ-600 |
Modle |
JXRA Ⅲ-600 |
||||||||||||
Working width(mm) |
600 |
Working Thickness(mm) |
2~80 |
||||||||||||
Feeding Speed(m/min) |
5~15 |
Shortest working length(mm) |
300 |
||||||||||||
Size of coating roller(mm) |
750×240 |
Size of doctor roller(mm) |
750×150 |
||||||||||||
Power of doctor roller(kw) |
0.37 |
|
|
||||||||||||
Convey power(kw) |
0.75 |
Zhujiang NMRW075-30 series |
Dalta VFD007M43B frequency converter(1) |
||||||||||||
Power of rubber roller(kw) |
0.75 |
Zhujiang NMRW075-60 series |
Dalta VFD007M43B frequency converter(2) |
||||||||||||
Electro-optic power(kw) |
0.37 |
Zhujiang NMRW050-40 series |
Dalta VFD007M21A frequency converter(2) |
||||||||||||
Total power(kw) |
8.99 |
Size(mm) |
1800×1660×1580 |
||||||||||||
Remark:Total power of the double heating barrel(kw):14.99 | |||||||||||||||
| |||||||||||||||
