Water Well Drilling Rig & Water Well Drilling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Gold
Model Number:
Water Well Drilling Rig
Payment & Shipping
Payment Methods:
Port of Shipment:
chongqing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Well Drilling Machine, Deep Water Well Drilling Rig,water Well Drill Rigs for Sale, Drilling RigNegotiableMOQ: 1 Set -
2015 Small Water Well Drilling Rig for SaleNegotiableMOQ: 1 Set
-
HZ-130YY Water Drilling Machine for SaleNegotiableMOQ: 1 Set
-
Geological Drilling Machine GX-50 Railroad/Highway/Bridge Tunnel/Power Station Geological Exploration EquipmentNegotiableMOQ: 1 Set
-
Hydraulic Trunnel Drilling Rig for Hydro-power Station, Geological Drilling EquipmentNegotiableMOQ: 1 Set
Place of Origin
Chongqing, China
Brand Name
Gold
Model Number
Water Well Drilling Rig
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Water Well Drilling Rig & Water Well Drilling Machine
1. APPLICATIONS:
This drilling machine is newly designed and manufactured according to the requirement of foundation engineering, suitable for drilling medium mini-type grouting hole of building, skyscraper, dam and harbor and drilling water well.
2. FEATURES
Mast structure, top-drive head can move down or up along with, strength and rigidity
Large torque, compact structure, easy to move
Top-drive head is equipped with hydraulic chuck, drilling Efficiently.
Reasonable arrangement, easy to operate, smooth and quick.
Technical Specifications
| hole dia (mm) | 600 | |
| drilling capacity (m) | 30 | |
| topdrive head speeds(r/min) | forward | 40;118;218;300 |
| reverse | 62 | |
| max torque (N.m) | 4500 | |
| topdrive head max pull force (KN) | 58.86 | |
| topdrive head max pulsh force (KN) | 44.15 | |
| top-drive head stroke (mm) | 700 | |
| hoist lift capacity with singlerope (KN) | 30 | |
| retracting stroke (mm) | 580 | |
| oil pump | CB32 oil gear pump | |
| power unit | electric motor for rotary | Y180L-4 22KW |
| electric motor for hoist | Y160M-4 11KW | |
| innerdia if spindle (mm) | 2200×1200×2050 | |
| drill body weight(kg) | 2500 | |
