Specifications
Auto-record (attached memory card),color video intercom ;color video door phone,Talk, Unlock, Monitor, Color video, 16 melodies
- Aluminum alloy panel of indoor unit,brand-new,elegant and fashionable.
- Auto-record 200 pieces of pictures(If have anyone moves in the monitoring area,the camera will take pictures and record them automatically)
- Guard against disassembly,anti-hit,waterproof,wearable zinc alloy outdoor station.
- 7"TFT,nonradiative,energy saving and high definition picture and wide view.
- Hand free intercommunication.
- Unlock electric lock.
- Monitor outside 16 piece melodies for choice.
- Volume, chroma and brightness could be adjusted.
- Supply one transformer and 15M cable for connection.
- The color video door phone is easy to install.
Parameter |
Specifications |
Unit |
Screen Size |
7.0(16:9) diagonal) |
Inch |
Display Format |
1440(H)X234(V) |
dot |
Active Area |
154.08(H)X86.58(V) |
mm |
Dot Pitch |
0.107(H)X0.370(V) |
mm |
Pixel Configuration |
Stripe |
|
Outline Dimension |
166.0(w)X100.0(H)X7.2(D)(typ.) |
mm |
Auto-record 7"TFT video door phone with memory Indoor unit:
- Input voltage:AC110-120V/60Hz or AC220-240V/50Hz
- Talk time delay:120s+10%
- Monitor time delay:40s+10%
- Working distance:50M(6X0.65mm2)
- Visual angle:78 Wide-angle
- Working temperature:-5C-40C
- Relative humidity:10%-90%(RH)
- Outline Dimension:166(W)X100(H)X7.2(D)mm
Outdoor unit
stalltion
1. Take off the screws on the bottom and remove the front cover.
2. This kind video door phone only one to one model
3. 1.4m-1.7m from the ground (according to the camera effect).avoid direct sunshine.
4. Fix the unit on the wall with screws(included)
5. Cover the aluminium alloy panel and tighten up the screws one the bottom.
Pakage
LUCKARM Video door phone #063:
