API standard Hydralic power tong for sucker rod 5/8" to 1 1/8"
Features
Sucker rod power tong is an other special purpose machinery to load or unload all kinds of sucker rods in oil field workover operations. The features are as follows,
1.According to various specifications of sucker rod equipped with corresponding jaw plate
2.can choose torque control valves
3.the lord clamp can choose tong dies
Technical Parameters
Model |
XQ28/1.8Y |
XQ28/2.6Y |
The range of master tong |
Sucker rod GYG 16 19 22 25 28,Φ48~60 oil tube5/8"~11/8" |
Sucker rod GYG 16 19 22 25 28 5/8"~11/8" |
the range of Back tong |
Sucker rod GYG 16 19 22 25 28,Φ48~60 oil tube 5/8"~11/8" |
Sucker rod GYG 16 19 22 25 28 5/8"~11/8" |
High gear rated torque |
700 N.m |
1000 N.m |
Low gear rated torque |
1800 N.m |
2600 N.m |
High gear rated speed |
104 r/min |
98 r/min |
Low gear rated speed |
40 r/min |
32 r/min |
Rated the system pressure |
10 MPa |
10 MPa |
Maximum supply oil |
65 L/min |
80 L/min |
|
Overal dimension L×W×H(mm) |
543×334×404 |
670×383×490 |
Removed quality(including back clamp) |
105 kg |
100kg 220lbs |
