Description:
DYP-ME003K4 is an automatically control products,which is based on the technology of infrared. There are the features of high sensitivity,strong reliability and the operating mode of ultra-low-voltage. It was used widely in all kinds of automatic induction equipment, especially the automatical control products,which was provided the power supply by dry battery.
Applications:
1 Human induction lamps and lanterns;
2 Human induction toys;
3 Security products;
4 Industrial automation and control;
5 Automatic induction electric equipment;
6 Battery-powered automatic control;
Features:
1 Absolutely automatic induction: It will output the high level when people enter the induction range;It will be automatic delay then turn off high level and output low level after people leaving. Distance is slightly shorter, the temperature compensation can be used for certain performance compensation;
2 Photosensitive control: be optional,but default as none;
3 Two trigger modes: It is selected by jumper;
4 Output high level signal;
Electrical parameters:
Operating voltage range |
DC 4.5-20V |
Quiescent current |
<60uA |
Level output |
High: 3.3 V /Low: 0V |
Mode of trigger |
L: non-repeatable trigger/H: repeatable trigger (default) |
Delay time |
Default:5S(5-200S,it’s adjustable),it also could be customized in zero a few seconds to dozens of minutes; |
Blockade time |
Default as 2.5S, could be customized in zero a few seconds to a few dozen seconds |
Dimensions of the board |
32mm X 24mm |
Dimension of Outer Housing |
52mm(L)*36mm(W)*23mm(H) |
Length of lead |
20 cm |
Angle of induction |
<110°Cone angle |
Sensing distance |
within 7 m |
Operating temperature |
-20°C - +80°C |
size of induction lens |
Diameter:23mm(default) |
