Waterproof IP65 5050rgb smd 3leds/pcs 30mm pixel led
Product Description:
1. Individually control: 1PCS LED pixel & 1IC (WS2801)
2. Waterproof: Yes IP66, with silicon glue waterproof protection.
3. Installation: Easy to install, you'd better drill the hole about 30-31mm.
4. Power supply: You must use a 12V DC power supply to power this pixel, do not use higher than 13V
or you can destroy the entire pixel.
5. Combination: PVC shell(thermostability, cold-resistant, resistant to UV) and PCB board, connector cables.
6. With features of high brightness, low power dissipation, long lifespan, low Voltage, low decline, colorful.
7. Connetors: 4PIN JST female and male connectors, also can be waterproof connectors, DAT, CLK, DC12V+, GND-,each led pixel is seperate, you can connect them one by one via male and female connectors easliy.
8. Color and effect: addressable lights you can set to any color, or animate, like running water,chasing and scanning etc. depending on the different installation methods may compose different dynamic effect of different color's character and design
9. Factory sales directly, good quality and price, offer 2 years warranty and quikly after-sale service.
10. Brand: iPixel LED
Feature:
| Product Name | 30mm 3LEDs/pcs led pixels |
| Product No. | P30V12 |
| LED Chip | Epistar SMD 5050 RGB LED chip |
| IC Chip | WS2801 |
| Input Voltage | DC12V |
| Watts | 0.72W/PCS |
| Cover Color | Milky cover |
| Connectors | 4PIN JST, also can be waterproof connectors |
| Beam angle | 140 |
| Certification | CE, RoHS |
| LED Qty | 3LEDs/pcs |
| Cable Length | 10cm usually, also can be customized |
