Service drop line ABC cable aerial bundled cable overhead ABC cable
Applcation
It is preferred to use of ABC cables instead of uninsulated conductors at low voltage networks. ABC cables are especially
used at areas where the cost of underground networks is expensive and also for electrification of rural areas like villages.
Bundles can include one or two additional conductors for public lighting and control pair.
Standard:
According to IEC,also can do by standard of ASTM,BS,GB,DIN and AS/NZS or other standards.
Construction:
Conductor:Aluminium or Aluminium alloy or Copper;
Bare Conductor may be made of AAC,ACSR,AAAC etc.
Insulation:PVC or XLPE or PE
Inner sheath:PVC or PE
Cores:Single,Duplex.Triplex,Quadruple
section: 10mm2, 16mm2, 25mm2, 35mm2, 50mm2, 70mm2, 95mm2 120mm2, 150mm2, 185mm2, 240mm2
Characters:
Rated Voltage is 0.6/1KV.
a.Max operating temperature :XLPE insulation 90°C,PVC or PE insulation 70°C.
b.Installing temperature of cable should not be below -20°C.
c.Max short-circuit temperature,Not more than5 Sec:XLPE insulation 250°C,High-density PE insulation 150°C,PVC insulation 130°C.
d.Permissible Bending radius of cable: when overall-diameter(D) is less than 25mm,It should be not less than 4D.when D is 25mm or more,It should be not less than 6D.
Rated Voltage is 10KV.
a.Max operating temperature :XLPE insulation 90°C,High-density PE insulation 75°C,PVC insulation 70°C.
b.Installing temperature of cable should not be below -20°C.
c.Max short-circuit temperature,Not more than5 Sec:XLPE insulation 250°C,High-density PE insulation 150°C,PVC insulation 130°C.
d.Permissible Bending radius of cable:Should be not less than 20(d+D)±5%mm. Where:D is overall diameter of cable; d is diameter of conductor.
Product description
| Type | Description | Application | |||||
| JKV | Rated voltage 1kV copper core PVC insulation aerial cable | Aerial fixed installation,lead door line | |||||
| JKY | Rated voltage 1kV copper core PEinsulation aerial cable | ||||||
| JKYJ | Rated voltage 1kV copper core XLPEinsulation aerial cable | ||||||
| JKLV | Rated voltage 1kV aluminum core PVC insulation aerial cable | ||||||
| JKLYJ | Rated voltage 1kV aluminum core XLPE insulation aerial cable | ||||||
| JKLJ | Rated voltage 1kV aluminum core PE insulation aerial cable | ||||||
| JKLHY | Rated voltage 1kV Al alloy core PE insulation aerial cable | ||||||
| JKLHV | Rated voltage 1kV Al alloy core PVC insulation aerial cable | ||||||
| JKLHYJ | Rated voltage 1kV Al alloy core XLPE insulation aerial cable | ||||||
