Specification
PVC/ rubber insulated cables for solar power
Application
solar cable, intended for the interconnection of various elements of photovoltaic systems such as solar panel arrays. Suitable for fixed installations internal and external, within unprotected pipes, or in similar closed systems. The cable is tested to last 25 years
Data:
|
No. Of cores x Nominal cross sectional area (mm2) |
Nominal diameter of conductor mm |
Nominal diameter of Over insulation mm |
Nominal Diameter of cable |
Nominal weight Kg/km |
1x1.5 |
1.6 |
3.1 |
4.8 |
39.80 |
1x2.5 |
2.0 |
3.5 |
5.2 |
52.20 |
1x4.0 |
2.6 |
4.3 |
6.0 |
70.71 |
1x6.0 |
3.2 |
4.7 |
6.7 |
102.60 |
1x10.0 |
5.0 |
6.7 |
9.0 |
153.90 |
1x16.0 |
6.0 |
7.7 |
9.9 |
230.50 |
1x25.0 |
7.3 |
9.0 |
11.2 |
340.00 |
1x35.0 |
8.7 |
10.4 |
12.6 |
422.0 |
Package & Delivery
wooden drums seaworthy or according to your requirements
delivery within 15 working days
