China Supplier High Quality Veneer Glue Spreader Machine
US$ 5,000 - 8,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, glue spreader
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Double Sides Automatic Glue Spreader Machine/plywood Core VeneerUS$ 5,000 - 8,500MOQ: 1 Set -
Glue Dispensing Machine/wood Veneer Glue SpreaderUS$ 3,500 - 6,500MOQ: 1 Set
-
CNC Controlled Double Sides Automatic Glue Spreader 1100mm WidthUS$ 5,000 - 8,500MOQ: 1 Set
-
Venner Glue Spreader/roll on GlueUS$ 1,700 - 2,800MOQ: 1 Set
-
Glue Spreading Machine, 8 Feet Plywood Core Veneer Glue MachineUS$ 5,000 - 8,500MOQ: 1 Set
Condition
New
Type
Other, glue spreader
Place of Origin
Shandong, China
Brand Name
JINLUN
Model Number
TJ-4x8
Voltage
380v
Power(W)
7.5kw
Dimension(L*W*H)
1700x1500x1900mm
Weight
500kg, 500kgs
Certification
CE
Warranty
1 years
After-sales Service Provided
Engineers available to service machinery overseas
Plywood glue spreader machine is one of the main equipments of the plywood production, it is will be after
modulation good adhesive evenly coated to the surface veneer of mechanical equipment.
According to the number of plywood glue roller coating machine, can be classified into double roller coating machine,
three roller coating machine and four roller coating machine three forms.Process performance is poor due
to the double roller coating machine, glue quantity is not easy to control, easy to crush veneer and low
production efficiency of defects, so use more glue to glue roller.
Plywood glue spreader machine consists of frame, glue roller, plastic bucket, retarding mechanism, adjusting
device,etc.
Descriptions
| Modle | SMTJ-1400 | SMTJ-2700 |
| Max. Processing Length | 1400mm | 2700mm |
| Rubber Roller Diameter | 250mm | 310mm |
| Max. Working Thickness | 70mm | 70mm |
| Spread Speed | 24-90m/min | 12-60m/min |
| Chromate Treatment | 210mm | 240mm |
| Roller Diameter | ||
| Number of Roller | 4 | 4 |
| Motor Power | 3kw, 380V-50Hz | 5.5kw, 380V-50Hz |
| Overall Dimension | 2200x1200x1400mm | 3400x1200x1300mm |
| Weight | 800kgs | 2200kgs |
| Payment terms | T/T 30% | T/T 30% |
| Delievry time | In 20days | In 20days |
