Descriptions of production:
The machines with its frame structure, is easy to handle and convenient to use. The two deckle boards, with its holistic processing, are of the same size. This ensures no error on the depth of parallelism; the up and down platforms, are processed after being distressed and annealed. This helps keep its shape. The hot plates, being ground finished, ensures an error of less than 0.01.
1. Frame Type Plate Vulcanizer is used for pressing rubber products and thermoseting plastic products, also and be used for seals, project rubber and rubber plate etc.
2.This series of producs have high press in unit area, so that we can ensure the quality.
3.Machine can be equiped with model pulling and pushing device to reduce work strength based on product requirements.
4. Hand control, electrical control and PLC control is optional.
5. About the voltage of this kind of machine, we can make it according to your requirements.
Technical data:
Type |
800*800 |
1000*1000 |
1200*1200 |
1500*1500 |
Nominal clamp mould force |
1.6mn |
2.0mn |
2.5mn |
3.15mn |
Piston size |
800*800 |
1000*1000mm |
1200*1200mm |
1500*1500mm |
Number of cylinder |
1 |
1 or 2 or 3 pieces |
1 or 2 or 3 pieces |
1 or 2 or 3 pieces |
Piston diameter |
¢360mm |
¢400mm |
¢450mm |
¢500mm |
Stroke of piston |
300mm |
300mm |
300mm |
300mm |
Distance between hot plate |
300mm |
300mm |
300mm |
300mm |
Unit area pressure of hot plate |
2.5Mpa |
2.0Mpa |
1.8Mpa |
1.5Mpa |
Power |
3.0KW |
5.5KW |
8.0KW |
8.0KW |
Overall size(L*W*H)(mm) |
900*1600*2500mm |
1100*1900*3600mm |
1300*2100*4000mm |
1600*2450*4200mm |
Weight |
4000kgs |
5800kgs |
6800kgs |
8000kgs |
Close mould speed |
≥6 |
≥6mm/s |
≥6mm/s |
≥6mm/s |
Open mould speed |
≥4 |
≥4mm/s |
≥4mm/s |
≥4mm/s |
Pictures for reference:
Pictures of structure:
Packing:
Certification:
We can produce all kinds of rubber machines according to client's requirements.
With many years producing and selling experiences, we try our best to produce high quality, high standard products based on aim, of which is "strive for survival by quality; produce by technology; creat market by good faith; be famous all over the world by brand".our products are sold to all over the world, and they are approved by our customers.
After Sales Service:
1. We will offer you one year guarantee
2. We will give you reply and solution within 24 hours.
