Qingdao Rubber Vacuum Double Compression Molding Machine
US$ 1 - 100,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
JINRUNQI
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
50 Tons -- 200 Tons Big Size Press Machine / Plate Vulcanizing Machine (auto Control)US$ 20,000 - 50,000MOQ: 1 Set -
Rubber Machine For Making Rubber Seal/rubber Seal MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
Rubber Seal Ring Plate Vulcanizer / Rubber Processing MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
Ring Vulcanizing Machine / Rubber Plate Vulcanizing Press / Rubber Hot PressUS$ 20,000 - 50,000MOQ: 1 Set
-
Chinese Golden Supplier Rubber Vulcanizing Press/Vulcanizer O Ring Vulcanizing MachineUS$ 20,000 - 50,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
JINRUNQI
Model Number
250T
Voltage
as client's requirements
Power(W)
30KW
Weight
kg
Certification
ISO/CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Qingdao Rubber Vacuum Double Compression Molding Machine
Specifications
Quality control: ISO 9001:2000
Stable performance, reasonable price and prompt service
Perfect after-sales service
| Characteristics: |
| The machine structure after the computer pressure, the strain analysis, |
| the service life is long-time; |
| The special heating platen design, the temperature distribution is even, |
| guarantees takes shape the quality disposable; |
| The fluctuation track organization, guarantees the sliding panel and the |
| heating platen does not rub; |
| The high efficiency fast vacuum system, the end product lack materials, the |
| gas-free does not soak. |
| Hydraulic system |
| The hydraulic pressure unit and an organism body, the design are artistic, |
| not oil leak, also may choose the proportion type . |
| Electrical system |
| PLC matches touches the screen control, enhances the product |
| type | 100T | 200T | 250T | 300T | 500T |
| Stroke(mm) | 250 | 250 | 250 | 250 | 300 |
| Working table(mm) | 400×400 | 503×508 | 600×600 | 650×650 | 650×740 |
| Piston diameter(mm) | 250 | 355 | 400 | 450 | 560 |
| Electrical heater(kw) | 13 | 13 | 15 | 15 | 17 |
| Motor HP(KW) | 10 | 10×2 | 10×2 | 10×2 | 15×2 |
| Vacuum pump motor(KW) | 4 | 4 | 4 | 4 | 4 |
| Total power(KW) | 20 | 28 | 30 | 30 | 32 |
| Mold opening method | up liter/down drop in/out-mold | ||||
| 2RT(Front Ejector) 3RT(Middle Mold) 4RT(Top Mold) | |||||
Pictures for reference:
Structure pictures:
Company Information
We are QINGDAO Jinrunqi Rubber Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email
Also we can make non-standard rubber machinery as customer’s requirements.
