AC 600KG Electric Door Motor for Roller up Shutter Door

AC 600KG Electric Door Motor for Roller up Shutter Door thumbnail-1
AC 600KG Electric Door Motor for Roller up Shutter Door thumbnail-2
AC 600KG Electric Door Motor for Roller up Shutter Door thumbnail-3
AC 600KG Electric Door Motor for Roller up Shutter Door thumbnail-4
AC 600KG Electric Door Motor for Roller up Shutter Door thumbnail-5
AC 600KG Electric Door Motor for Roller up Shutter Door photo-1
AC 600KG Electric Door Motor for Roller up Shutter Door photo-2
AC 600KG Electric Door Motor for Roller up Shutter Door photo-3
AC 600KG Electric Door Motor for Roller up Shutter Door photo-4
AC 600KG Electric Door Motor for Roller up Shutter Door photo-5
US$ 40 - 79 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
YADALONG
Model Number:
JD--600-3P
Contact Supplier Request Quote Chat Now
Fujian Yadalong Motor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Fujian China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name YADALONG
Model Number JD--600-3P
Usage Other, Door motor
Certification CCC, CE
Type Tubular Motor
Torque 412N.m
Construction Permanent Magnet
Commutation Brush
Protect Feature Waterproof
Speed(RPM) 4.4r/min
Continuous Current(A) 0.2A
Output Power 400W
Voltage(V) 380V
Efficiency IE 4

AC 600KG electric door motor

for roller up shutter door

Product Description

YADALONG rolling shutter door motors used to shopping centers, warehouses, garages, theaters, hotels, banks, factories and other buildings, rolling shutter door’s opening and closing, with electric and manual function.



Roller shutter door’s opening and closing operation are power-driven, the up and down stroke was automatic controlled by limit switch. Accurate and reliable positioning, opening and closing security.



Equipped with a motor winding overheating protection device, it will automatically cut off power supply when the temperature reaches 110 °,so to protect the motors from being burned,and the device can start again when the temperature dropped to 70 ° (after about 8min).



Features of rolling shutter door motor.

1. Our rolling door motor with good design, advance structure, large starting torque, short-time duty.

2. Easy installation, legerity design, stable operation, low noise, small power consumption

3. Low noise, Small power wastage, little vibration.

4. Remote control system

5. Limit switch unit enables precise adjustment of door in both up and down positions.

6. Electric and manual operation

Technology Parameter
Technology Parameter
FUJIAN YADALONG MOTOR CO.,LTD
Model Rated Power (w) Lifting force
(kg.f) 		Rated load Max lifting height(m) Type of chain Motor Weight             (kg)
Output Torque   (N.m) Output speed   (r/min)
AC single-phase rolling door motor  220V   50-60HZ
JD-300-1P 250 300 168 5.4 4.5 08B 12
JD-500-1P 370 500 343 5.2 6 10A 13
JD-600-1P 370 600 412 5.3 6 10A 13
JD-800-1P 550 800 647 4.4 9 10A 14
JD-1000-1P 550 1000 809 4.4 9 10A 15
AC three-phase rolling door motor 380V   50-60HZ
JD-600-3P 250 600 412 5.3 6 10A 13
JD-800-3P 300 800 647 4.6 9 10A 14
JD-1000-3P 550 1000 809 4.4 9 12A 14
JD-1300-3P 600 1300 1401 4.4 9 12A 14
JD-1500-3P 800 1500 1617 5.2 9 12A 15
DC rolling door motor  220V   50-60HZ
JH-300 290 300 210 5.4 4.5 08B 12
JH-600 380 600 410 5.3 6 10A 13
JH-800 550 800 686 5.3 9 10A 14
Company Information

Porducts  Details

Our Brand:

AC 600KG electric door motor for roller up shutter doorAC 600KG electric door motor for roller up shutter door

AC 600KG electric door motor for roller up shutter door

AC 600KG electric door motor for roller up shutter door

AC 600KG electric door motor for roller up shutter doorAC 600KG electric door motor for roller up shutter door

  AC 600KG electric door motor for roller up shutter door

YADALONG Automatic EQUIPEMNT

AC 600KG electric door motor for roller up shutter door

Our Package

AC 600KG electric door motor for roller up shutter doorAC 600KG electric door motor for roller up shutter door

Certifications

Certifications

AC 600KG electric door motor for roller up shutter door

Our Services

Our Service:



1 Any inquiry/question will be reply in 24 hours during working days.

2 Sample order: Available, the customers should charge the sample fee and freight cost.

3 OEM for customers is available.

4 Delivery time: 2-4 weeks after receipt of the deposit or LC at sight.

5 Terms of Payment: T/T, LC, etc.

6 Warranty: 1 Year from BL date

7  Packing: Carton packed fill with foam; One set in 2 cartons: 1ctn for main motor, 1 ctn for bracket and  accessories

8 100% copper material inside the motor

FAQ

Any question



1.Can you do OEM for me?

Yes! We accept all OEM orders, please contact us and give us your requirement, we will offer you a reasonable price and make  samples for you ASAP.

 2.Can you supply me samples?

 Yes, we will give you samples if you want, but you have to pay the fee for freight and samples .

 3.What is your delivery time?

 Within 20 days after receipt of deposit.

 4.What is the shipping port?

 We ship the goods via Xiamen Port.

 5. I wonder if you accept small order?

 Don't be hesitated to contact us, we accept small order.

 6.What are your main products?

 Our main products are rolling door motors, sliding gate openers and the accessories.
