64CH 2U Box NVR

Name: 64CH 2U Box NVR
Brand: Ratingsecu
SKU: 130012965

US$ 480 - 495 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

Ratingsecu

Model Number:

R-QN6864A

Contact Supplier Request Quote Chat Now

Shenzhen Rong Tian Shi Tech Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Ratingsecu

Model Number R-QN6864A

64CH 2U NVR

Product Description

Features:

Support 64CH 720P or 960P or 36CH 1080P HD IP cameras, total 256M.
* Playback channels: 1 / 4 / 9 CH Synchronous playback
* Support ONVIF, 8 SATA (each max 4TB)
* Interface: HDMI X 1, VGA X 1, audio output X 1, USB X 3, E-SATA X 1, 1000M RJ45 X 2, 4CH alarm in + 1CH alarm out
* RS 485 X 1 can use NVR keyboard
* Size / weight: 440 mm × 450 mm × 90 mm / 10.5 Kg

Technical parameters:

Model:		R-QN6864A
Box:		Standard 2U box
Operate system:		Embedded LINUX operate system
Image coding standard:		H.264 / MPEG4 AVC
Image coding control:		Can adjust image coding, variable stream, limited stream optional
Dual stream:		Each channel can set main and auxiliary stream
Audio compression:		G.711
Video Standard:		PAL/NTSC
Monitor image quality:		1080P (1920 x 1080) 30 frames / sec ; 960P / (1280 x 960) ; 720P (1280 x 720) 30 frames / sec.
Image playback quality:		4CH 720P	1 / 4 / 9 CH Synchronous playback
Regional block set:		Each channel support four regional block (need IPC support)
Intercom:		2 ways voice intercom
Video mode:		Support manual, auto, dynamic monitoring, alarm triggered recording mode (part needs IPC support)
Backup mode:		Support U disk, USB mobile hard disk, burner, network storage, backup
Save video:		Local hard disk
Operate mode:		Mouse
Network video input:		4CH	8CH
Network audio input:		4CH	4CH
External interface	Video output:	1CH VGA+1CH HDMI
	Audio output:	1CH RCA
	Alarm input:	No
	Alarm output:	No
	Network interface:	1pc RJ45 10M / 100M Adaptive Ethernet port
	WIFI interface:	3G, WIFI
	RS485 interface:	No
	USB interface:	USB 2.0 interface: 3(1 at front plate, 2 at back plate)
Local log on:		User name and password
Hard disk:		One SATA interface, support single largest capacity 4TB hard disk
Power supply:		DC12V / 2.6A
Mobile surveillance:		Support(iPhone,Symbian,Android)smart mobile phone
Power consumption:		≤ 25W (without hard disk)
Working temperature:		-10 ^oC ~ + 55 ⁰C
Working humidity:		10%-90%
Size:		Machine: 260mmx220mmx 43 mm, contain the packaging: 355 mmx 255mmx 88.5 mm
Weight(without hard disk):		Net weight:1.5 kg, contain the packaging: 2.4 kg
