Help CenterPvc Extruder/ Double Screw Extruder China Supplier
Related Products
Specifications
pvc extruder/ double screw extruder china supplier1. CE&ISO
2. high plasitify with low consumpt
3. Turn-key project
pvc extruder/ double screw extruder china supplier
1. CE&ISO certification
2. high plasitify with low consumpt
3. Turn-key project
4. double screw extruder for pipe/profile
Features Specifications:
1. Model SJSZ series double screw extruder is a kind of special equipment for extruding PVC compound. With different kinds of molds and auxiliary machines, it can produce all sorts of PVC plastic pipe, profile, plate material, sheet material, bar material and granulation.
double screw extruder for pipe/profile
3. The conical twin screw extruder system has applied special computer control. According to customers requirements, most reasonable structure of conical twin screw can be made so as to achieve best plasticity performance and material quality.
4. The conical twin screw is made by high precision special digital screw miller; extruding property can be highly harmonized. It has firstly introduced advanced technique of producing screw with variable pitch and depth, so that the material can be more softly sheared and cut.
5. The distribution box is specially designed, pull force bearing is fully imported, and the drive life span can be prolonged. It can bear larger extruding pressure.
6. The electrical system has mainly applied imported parts, it has multiple alarm system, and there are few problems which can be easily eliminated. The cooling system has applied special design, heat emission area is enlarged, the cooling is rapid, and temperature control tolerance can be ± 1degree.
| Model number | Screw diameter (mm) | Rotational speed of screw (rpm) | Effective work length (mm) | Main motor power (kw) | Heating power of Barrel (kw) | Production capacity (kg/h) | Central height of machine (mm) | Net weight | Overall size (mm) |
| SJSZ45 | 45/90 | 1-45 | 1070 | 15 | 9.6 | 70 | 1000 | 2800 | 3300*1200*2000 |
| SJSZ51 | 51/105 | 1-45.5 | 1100 | 22 | 11.5 | 80 | 1000 | 3000 | 3360*1290*2100 |
| SJSZ55 | 55/110 | 1-40 | 1200 | 22 | 18 | 150 | 1000 | 3500 | 3620*1350*2200 |
| SJSZ65 | 65/132 | 1-38 | 1440 | 37 | 24 | 250 | 1000 | 4000 | 4235*1520*2450 |
| SJSZ80 | 80/156 | 1-36.9 | 1800 | 55 | 36 | 360 | 1000 | 5000 | 4750*1550*2460 |
| SJSZ92 | 92/188 | 1-34.7 | 2500 | 110 | 88 | 1000 | 1000 | 5500 | 6000*1600*2500 |
