Help CenterTransparent Clear PET Thermal Film for Laminating and Printing
Related Products
Specifications
1.Pet thermal film for laminationg and printing2.Both sides with corona treated
3.Good bonding
4.Supply in roll
5.SGS
Specification:
1.printing material
2.Both sides with corona treated
3.Good bonding
4.Supply in roll
5.SGS Certificate
Matt BOPP laminating film with glue
Environmentally friendly:It is environmentally friendly,non-hazardous to health and safe to use as no toxic gases or volatile content is emitted.Safety in laminating process as no solvent based adhesive is used.
High function: Compared with other solvent lamination, our film is better in clarity and bonding. Strong ability of absorbing powder, It prevents lamination from being pressed, bubbled and shredded off easily. Matt thermal lamination film is good for spot UV and hot stamping.
Easy handling:It is easy to operate once the required temperature is met and no special technique required.
Efficient and energy-saving: Production cost is reduced substantially as there is no film wastage, mixture of adhesive solvent, and no UV heating lamp is required.
Adaptable to different kinds of machines: This film is recommended to be used in dry laminator. Small adjustments need to be made to the machine if the film is used in wet laminator.
Process Parameter:
Equiement for laminating film: dry and wet film laminator
Temperature: ~100°C / Special: 100~110°C
Roller Pressure: 10~18Mpa
Speed: 8~50m/min
Remarks: special laminations refer to those with thicker ink,solid color,high moisture content and bigger size paper.
Application manual:
1. Adjust roller pressure and temperature according todifferent types of paper and ink.
2. When using the film for the first time or changing to other sizes,we recommend a small trial volume before
going into fully mass lamination.
3. The following situation will affect the quality of the film during lamination.
a.When using metal ink
b.When the ink contains too much wax, dried oil, adhesive, and silicon additive. etc.
c. When the ink is too thick.
d.When the ink is not completely dry
e.When the paper contains too much moisture
f.When there is too much powder
Product specifications and paramete
| SPECIFICATION |
17GLOSS/ MATT |
18GLOSS/ MATT |
19GLOSS/ MATT |
20GLOSS/ MATT |
22GLOSS/ MATT |
24GLOSS/ MATT |
27GLOSS/ MATT |
30GLOSS/ MATT |
|
| THICKNESS | BASE | 12 | 12 | 12 | 12 | 12 | 12 | 15 | 18 |
| EVA | 05 | 06 | 07 | 08 | 10 | 12 | 12 | 12 | |
| TOTAL | 17 | 18 | 19 | 20 | 22 | 24 | 27 | 30 | |
| WIDTH | 360 390 440 540 590 780 880 1080 1320 1400 1600 1800 Up customer's requirement | ||||||||
| LENGTH | 200-6000 more or less 10% allowed | ||||||||
| PAPER CORE | 25.4mm(1inch), 50.8mm(2inch), 76mm(3inch) | ||||||||
| BONDING | LESS THAN 2 | ||||||||
| TENSILE STRENGTH | MD:2.4x106 dyne/cm CD:5.3x106 dyne/cm | ||||||||
Products Show
