2.5mm2 House Wire Copper Core Pvc Insulated Electric Wire

Name: 2.5mm2 House Wire Copper Core Pvc Insulated Electric Wire
Brand: ShangJin or OEM
SKU: 130257299

US$ 10 - 500 MOQ: 100 Rolls

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

ShangJin or OEM

Model Number:

Cu / PVC

Shanghai Yongjin Cable Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name ShangJin or OEM

Model Number Cu / PVC

Type Insulated

Application Other, building light

Conductor Material Copper

Conductor Type Solid

Insulation Material PVC

Specifications

this product is fit for AC rated voltage under than 450/750v ,
IEC standard with CCC ISO CE GOST certificate.

Style ====>

227 IEC 01 (BV) : General purpose single core solid conductor pvc sheath electric wire .

BV : Cu/PVC

BV-90 model not more than 90°C,other not more than 70°C,installation temperature not lower than 0°C.

this cable is fit for AC rated voltage below than 450/750V.

the length of cables should be in according to mutual agreements .

BV
Nominal section(mm2)	No.Dia. of Core (mm)	Max outer diameter (mm)	Conductor resistance at 20C(≤Ωkm)	standard thickness of insulation	kg/100m weight
0.5	1/0.8	2.4	36	0.6	0.88
0.75(A)	1/0.97	2.6	24.5	0.6	1.12
0.75(B)	7/0.37	2.8	24.5
1(A)	1/1.13	2.8	18.1	0.6	1.4
1(B)	7/0.43	3	18.1
1.5(A)	1/1.38	3.3	12.1	0.7	2
1.5(B)	7/0.52	3.5	12.1
2.5(A)	1/1.78	3.9	11.8	0.8	3.2
2.5(B)	7/0.68	4.2	—
4(A)	1/2.25	4.4	7.39	0.8	4.6
4(B)	7/0.85	4.8	—
6(A)	1/2.76	4.8	4.91	0.8	6.7
6(B)	7/1.04	5.4	—
10	7/1.35	7	3.08	1	11.2
16	7/1.70	8	1.91	1	16.8
25	27/2.04	10	1.2	1.2	26.2
35	27/2.52	11.5	0.868
