MF-90 Medium frequency induction heating equipment
Main specifications:
Model:MF-90
Maximum input power: 90KW
Maximum frequency: 1-20KHz (customized according workpiece requires.)
Maximum input current: 135A
Output current: 25-170A
Output voltage: 70-550V
Input voltage: 380VAC three phases, 50 or 60Hz (custom make according customer requires)
Duty cycle: 100%
Auto heating time: 0.1-99.9seconds
Auto retaining time: 0.1-99.9sedonds
Cooling water: ≥0.2Mpa ,≥6L/min
Generator size: (L x W x H):750 x 400 x 870mm
Generator weight:82KG
Compensating capacitor size (L x W x H):500 x 400 x 500mm
Compensating capacitor weight:65KG
Typical applications:
- ≤120KG of gold,silver,copper, brass melting.
- ≤40KG of steel, stainless steel melting.
- ≤40KG of aluminum , aluminum alloy melting.
- heat for matching of shaft into hole.
- Heat of steel or brass rod and nut for forging
- etc.
Medium Frequency melting furnace features:
1. Medium Frequency melting furnace for melting gold, silver, copper, iron, steel, stainless steel, aluminum and other metal materials
2. Medium Frequency melting good electromagnetic stirring, melting metal in favor of a uniform temperature and organizations in
favor of scum, reduce impurities
3.Frequency range, from 1KHZ to 20KHZ, can considering the amount of melting, electromagnetic stirring, heating efficiency,
noise and other factors when designing an induction loop and matching compensation capacitor determine the size of the output
frequency
4.SCR frequency ratio, saving more than 20% at least
5.Small size, light weight, melting capacity from a few kilograms to hundreds of kilograms, a great range of options, both for factory
use, but also for schools and institutes use a small amount of melting
6.Smelting capacity 24 hours a day
7, to facilitate the replacement of different weights, furnace different materials, different ways to suit the requirements of a variety
of melting.
The main smelting furnace and heating capacity models:
In the table below for the maximum heating capacity of each melting furnace, cold furnace smelting furnace every time is 50-60
The main models |
Maximum input power |
Largest smelting capacity |
||
Steel, stainless steel, iron |
Brass, copper, gold, silver, |
Aluminum, aluminum alloys |
||
MF-15 melting furnace |
15KW |
3KG |
10KG |
3KG |
MF-25melting furnace |
25KW |
5KG |
20KG |
5KG |
MF-35melting furnace |
35KW |
10KG |
30KG |
10KG |
MF-45melting furnace |
45KW |
18KG |
50KG |
18KG |
MF-70melting furnace |
70KW |
25KG |
100KG |
25KG |
MF-90melting furnace |
90KW |
40KG |
120KG |
40KG |
MF-110melting furnace |
110KW |
50KG |
150KG |
50KG |
MF-160melting furnace |
160KW |
100KG |
250KG |
100KG |
MF-240 melting furnace |
240KW |
150KG |
400KG |
150KG |
MF-300melting furnace |
300KW |
200KG |
500KG |
200KG |
