Specifications
1.enhance the workpiece life2.make the workpiece look pretty
3.large output
| Chamber Inner Size | Φ1000×1500mm² |
| Ultimate Vacuum Pressure | <1.3×10-³Pa |
| Pump Down Time(from atmosphere down to6.7×10-³Pa) | <20min |
| Number of Arc ion Evaporator | 8sets |
| Number of Large Rectangular Magnetron Sputtering Sources | 2 sets |
| Effective Coating Space | Φ750×1100mm² |
| Coating Cycle(Dec/Tool) | 50/180min |
| Total Electric Consumption (380V, 50Hz) | 70KW |
| Cooling Water Consumption | 3 Ton/hr |
| Sapce Occupation | 7×8×3m³ |
| Application | Decoration and Tool |
LD series multi-arc ion vacuum coating equipment use new type of arc source in the workplace,it is effective in reducing the number of big particles generated, reducing the size of particles, meanwhile the work is stable, it can work steadily for a long time in high-vacuum and low-current state, which is the vast majority of similar equipment that can not be attained. Therefore the bonding force of the film retia is well, and the film retias surface is smooth, it is high microhardness.
LD series coating machines,adopt PVD technique, outstand for their great performance at competitive prices.Multi-arcs ion coating machine model LD is physical vapor deposition facility equipped with 8 sets of arc ion evaporators. LD could be usded to coat serveral coatings (such as TiN, TiCN, CrN, TiAlN, DLC, W/C, etc.) on a great range of industrial products, (such as clocks, watches, ornaments, lamps, building hardware, work of arts, cutting and milling tools,aiguille, piercing mandrel, moulds, etc.) in order to improve their surface properties, (such as, high rigidity, abrasive resistance, corrosion resistance, anti-adhensive, anti-oxidation, etc)
Marketed for almost 15 years, LD PVD coating machine are well received at home and overseas, enjoying a high reputation for its good quality at competitive price. We research and develop coating technique and share with our customers. We would like to co-found a prosperous future with you.
