Help CenterWhite pu Conveyor Belt
Related Products
Specifications
1. material: pu2. color: white
3. ply: 2
We make pu guides to the pu surface to meet the customers requirements.
Pu conveyor belt is FDA.
* PRODUCT CONSTRUCTION *
Number of fabric:2 |
Color:White |
Number of fibre:2 |
Fibre type:Polyester,with lateral stability |
Material topside:PU elastomer |
Profile topside:Matte finish
|
Material bottomside:Polyester, antistatic |
|
* TECHNICAL DATA *
Total thickness(mm):1.5 |
Cover thickness(mm):0.3 |
Weight(Kg/M2): 1.8 |
Maximum production width(mm): 2000 |
Maximum tension(N/mm):150 |
Tensile force for 1% elongation (N/mm):10 |
Hardness toplayer(Shore A):93 |
Temperature article(°C):-20/+80 |
Minumum pulley diameter flection(mm):20 |
Minimumpulley Diameter contraflection(mm): 40 |
Lateral stability:Yes |
Oil and grease resistant: Yes |
Food grade:Yes |
|
* APPLICATIONS *
|
Flat transmission or roller wheel transmission Foodstuff industries |
