FEATURES:
1. Equipped with brushless converter motor that has high torque, high speed bearing from Europe with high quality, running smoothly and maintenance free.
2. Controlled by microcomputer with touching panel and LED display. Operating parameter can be saved automatically, RCF value can be set directly for working, easy to use.
3. Multistage damping system, the Freon-free compressor from European, Small vibration, low noise and slight vibration, green.
4. Stainless steel centrifugal chamber. Imports of key components, durable and easy to clean.
5. With rotor identification system, overspeed, overtemperature, door interlock, unbalance protection functions, and rotor service lifespan calculation to ensure safety.
6. A proprietary air flow guide design, makes the the centrifuge chamber temperature rise small, can effectively protect the sample. The proprietary SCT speed control design, fast acceleration and deceleration, high efficiency.
7. Adjustable acceleration and deceleration from grade 0-9 or directly set the time of Accel/Decel, and can be store 40 kinds of self-defining operating models, to achieve the best centrifugal result.
8. Hold-on and transient centrifuging, convenient for centrifugal diversification
TECHNICAL PARAMETER
Model |
TD5A-II |
Max Speed |
5500r/min |
Max RCF |
5310×g |
Max Capacity |
3000ml |
Speed Accuracy |
±20r/min |
Time Range |
0-99h59min59s |
Power Supply |
AC 220V 50Hz 15A |
Noise |
≤65dB |
Dimension |
460×590×420(mm) |
Net Weight |
45kg |
TD5A-II ROTOR:
Model |
No. |
Capacity |
Max Speed (r/min) |
Max RCF(×g) |
Dimension of tube (mm) |
Swing Rotor |
No.63 |
4×50/100ml |
5500 r/min |
5310×g |
Φ38×124 |
No.69 |
4×500ml (adaptor 12×50ml /8×100ml) |
4000 r/min |
3580×g |
Φ80×140 |
|
No.70 |
4×250ml (adaptor 8×50ml /36×10ml) |
4000 r/min |
3500×g |
Φ64×113 |
|
|
4×750ml |
4000 |
3580 |
|
|
No.77 |
32×10/15ml |
4000 r/min |
2810×g |
Φ16×85-118 |
|
No.81 |
8×50/100ml |
4000 r/min |
2810×g |
Φ38x124 |
|
No.82 |
48/40×5ml |
4000 r/min |
2800×g |
Φ14×54 |
|
No.84 |
148×7ml |
4000 r/min |
3200×g |
Immuno tubes |
|
No.84 |
120×7ml |
4000 r/min |
3200×g |
Blood tube |
|
Microplate Rotor |
No.44 |
2×2×96 holes |
4000 r/min |
2300×g |
Microtiter plate |
