Ophthalmic YZ50A Retinal Camera

Name: Ophthalmic YZ50A Retinal Camera
Brand: LINK Retinal Camera
SKU: 130476723

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

LINK Retinal Camera

Model Number:

YZ50A Retinal Camera

Shanghai Link Instruments Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name LINK Retinal Camera

Model Number YZ50A Retinal Camera

Retinal Camera YZ50A

Features:

·Split line provides the function of accurate focusing and makes the focusing more accurate and convenient;

·The use of pupil alignment spots eliminates stray light effectively;

·Targeting and focusing of infrared light improves greatly the feeling of patient comfort;

·Flash strength of eight adjustable forwards ensures suitable exposure;

·Functions of using periphery internal fixation standard, object images stitching and field-of-view can expanded to 77º

·Design of no eyepiece and colorful screen can target and focus conveniently and directly.

·With the function of right/left eye auto detection.

Specifications:

Images	Fundus color/red-free photography
View field	45º
Working Distance	41mm
Dioptric Compensation for Patient’s Eyes	-34D~+35D total -15D~+13D with no dioptric lens -34D~-14D with minus dioptric lens +12D~+35D with plus dioptric lens
Min Pupil Diameter	Φ3.7mm
Internal Fixation Target	3 in center, 6 in the periphery with 60 º detent interval
Backward and Forward Movement	45mm
Left and Right Movement	80mm
Up and Down Movement	30mm
Chinrest Movement	65mm
Input Voltage	AC220±22V/50Hz±1Hz, AC110V±11V/60Hz±1Hz
Input Power	300VA
Fuse	AC250V T3A
Light	12V/30W, Halogen
Electrical Safety Standard	GB9706.1-1995,ClassI Type B
Voltage Transformer Thermal Circuit Breaker	130℃
