GSM / DCS/WCDMA RF Combiner
US$ 60 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
XINLUN
Model Number:
XL-IN1K
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
XINLUN
Model Number
XL-IN1K
Specification |
PORT1 |
PORT2 |
PORT3 |
PORT4 |
Frequency (Range( (MHz) (MHz)Range (MHz) (MHz) (MHz) |
800~880 |
909~960 |
1710~1880 |
1920~2170 |
wideband (MHz) |
80 |
51 |
170 |
250 |
Insertion loss (dB) |
≤0.8 |
|||
ripple in band (dB) |
≤0.7 |
|||
VSWR |
≤1.25 |
|||
out-of-Band rejection (dB) |
≥80@909~2170MHz |
≥80 @800~880MHz ≥80@1710~2170MHz |
≥80@1920~2170MHz ≥80@800~960MHz |
≥80@800~1880MHz |
Third-order intermodulation (dBc) |
145@2×43dBm,160@2×43dBm |
|||
Max.powe (W) |
300,1000 |
|||
Working temperature |
-25℃~+55℃ |
|||
Working humidity |
≤95% |
|||
Work pressure |
86kPa~106kPa |
|||
Joint type |
|
|||
Dimensions(mm) |
236mm×149mm×50mm |
|||
