Detailed Product Description of 2 cavity bottle blow molding machine:
Double Cavity,1440bph for 1500ml, could blow all kinds of shapes, different volumes of beverage bottle, candy-jars, edible oil bottle, sauces bottle, detergent bottle, cosmetic bottle, medicine bottle, health products and other shapes of containers using PET as material.
Preform material:PET
Output:1440BPH(1500ml)
Features of 2 cavity bottle blow molding machine:
1.Using hydro-pneumatic linkage mold clamping mechanism which runs stably with high speed and great clamping force.
2.The control system adopts man-machine interface with Mitsubishi PLC which is of high sensitivity and accuracy.
3.Using coated infrared heating lamps which enable fast and stable heating.
4.Using centralized noise-reducing air recycling system which minimize the noise as much as possible.
5.Using slide core in stepping unit which is easy to operate and saves energy.
Machine Picture of 2 cavity bottle blow molding machine:
Product made by 2 cavity bottle blow molding machine:
Parameters of 2 cavity bottle blow molding machine:
Item |
HGA.C-2C |
|
Container |
Max. Container Volume |
1500 ml |
Neck Diameter Range |
50mm |
|
Max. ContainerDiameter |
100 mm |
|
Max. Container Height |
330 mm |
|
Theoretical Output |
1440 bph |
|
Molding |
Clamping stroke |
150 mm |
Stretching stroke |
450 mm |
|
Bottom Stoke |
50 mm |
|
Preform distance |
130 mm |
|
Preform Holder |
89 pcs |
|
Cavities |
2No. |
|
|
Electrical System |
Max. Heating Power |
32 kw |
Heating Power |
10 kw |
|
Air System |
Operating Pressure |
7 kg/c m2 |
Low Air Consumption |
1500 ltr/min |
|
Blowing Pressure |
35 kg/c m2 |
|
High Air consumption |
1600 ltr/min |
|
Cooling Water |
Operating Pressure |
5-6 kg/c m2 |
Temperature |
8-12°C |
|
Flow rate |
30 ltr/min |
|
Machine |
Size(L×W×H) |
2520×1750×1750mm |
Weight |
2600 kg |
|
Compressor High pressure
Compressor low air
Our 2 cavity bottle blow molding machine has already accquired the CE certificate:
Other domestic patents of our double cavity pet blow machine:
