HP6050 Mini Digital Clamp Meter
Specifications
1.Display: 3 3/4 digit LCD with a max. reading of 3999
2.Auto Power Off
3.DC Voltage to 1000V/ AC Voltage to 750V
AUTO RANGE DIGITAL AC CLAMP MULTIMETE
Function |
Range |
Resolution |
Accuracy |
Remarks |
|||
DCV |
400mV |
±0.8% of rdg |
0.1mV |
Input impedance: 400 mv file: > 10 m Ω, other file 10 m Ω . |
|||
4V |
±1.0% of rdg |
1mV |
|||||
40V |
10mV |
||||||
400V |
100mV |
||||||
1000V |
±1.5% of rdg |
1V |
|||||
capacity |
40nF |
±6.0 % of rdg |
10PF |
Overload protection:250V DC/250Vrms AC . |
|||
400nF |
±3.5% of rdg |
100PF |
|||||
4uF |
1nF |
||||||
40uF |
10nF |
||||||
100uF |
±6.0% of rdg |
100nF |
|||||
Ω |
400Ω |
±2.0% of rdg |
0.1Ω |
Overload protection:250V DC/250Vrms AC |
|||
4KΩ |
±1.0% of rdg |
1Ω |
|||||
40KΩ |
10Ω |
||||||
400KΩ |
100Ω |
||||||
4MΩ |
1KΩ |
||||||
40MΩ |
±2.5% of rdg |
10KΩ |
|||||
ACV |
Range |
Accuracy |
Resolution |
Accuracy |
input impedance :400mV:>100MΩ, Other files 10MΩ. |
||
400mV |
±3.0 of rdg % |
0.1mV |
50~400Hz |
||||
4V |
±1.5% of rdg |
1mV |
50~400Hz |
||||
40V |
10mV |
||||||
400V |
100mV |
||||||
750V |
±3.0% of rdg |
1V |
50~100Hz |
||||
Frequency and duty ratio |
10Hz |
±1.2 % of rdg |
0.01Hz |
0.6V rms AC |
Test sensitivity:0.6V rms AC./(10MHz:1.5V rms AC )/ Duty ratio test:0.1%~99.9% Overload protection:250V DC/250Vrms AC |
||
100Hz |
0.1Hz |
||||||
1000Hz |
±0.8% of rdg |
1Hz |
|||||
10KHz |
10Hz |
||||||
100KHz |
100Hz |
||||||
1000KHz |
1KHz |
1.5V rms AC |
|||||
10MHz |
±(2.0% of rdg |
10KHz |
|||||
ACA |
Range |
Resolution |
Accuracy |
Frequency |
Overload protection:1000Arms,Less than 60seconds. |
||
40A |
0.01A |
±3.5% of rdg |
50~60Hz |
||||
400A |
0.1A |
±3.5% of rdg |
50~60Hz |
||||
10000A |
0~800 |
1A |
±3.5% of rdg |
||||
800~1000 |
±0.5% of rdg |
||||||
Diode test &Audible Continuity Test |
Range |
Description |
Testing Range |
Overload protection:250V DC/250Vrms AC |
|||
testing DC:1.0±0.7mA |
Approx. 1.5V |
||||||
Built-in buzzer sounds if resistance is less than 50Ω |
Approx. 0.5V |
||||||
1. Function
DC /AC Voltage, AC Current, Resistance Capacitance, Frequency , Duty cycle , Temperature, Diode Continuity Test
Display: 3 3/4 digit LCD with a max. reading of 3999
AC Current to1000A
DC Voltage to 1000V/ AC Voltage to 750V
Clamp opening size: 1.57" (40mm)
Data Hold to freeze the displayed value
Back light
Auto Power Off
Power supply: "AA" 1.5V 5# two pieces
Safety:According to EN61010-1 protection class overvoltage category(CAT 600V) pollution degreen 2.
Certificate: CE Approval
2. Packing
Each item in one Plastic Portable Case
Dimension: 242(H)×80(W)×44(D)mm.
Ctn size: 595×333×490mm
QTY / Ctn: 20pcs
Gw/Nw: 20/19KG
