Home > Instruments & Meters > Electronic Instrument > Oscilloscope > HOT SALE! 20MHz, 1Gsa/s,Multi Triggering Modes Cursor Measurement Digital Storage Oscilloscope Tonghui TDO3062BS
HOT SALE! 20MHz, 1Gsa/s,Multi Triggering Modes Cursor Measurement Digital Storage Oscilloscope Tonghui TDO3062BS
US$ 720 - 900
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TONGHUI
Model Number:
TDO3062BS
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HOT SALE! Multi Triggering Modes, Cursor Measurement Functions, Digital Storage Oscilloscopes TDO3102BSUS$ 860 - 1,000MOQ: 1 Piece -
HOT SALE! 200MHz,1Gsa/s,Multi Triggering Modes Cursor Measurement Digital Storage Oscilloscope Tonghui TDO3202BUS$ 700 - 800MOQ: 1 Piece
-
AC100-240v SDS1102CNL 100MHz DSO Digital OscilloscopeUS$ 230 - 400MOQ: 1 Piece
-
New DSO5200 Digital Virtual Oscilloscope Hantek DSO-5200 Portable Oscilloscope USB 200MHz 250MS/s 2 ChannelUS$ 100 - 350MOQ: 1 Piece
-
Hantek HandHeld Oscilloscope DSO1200 Handheld 5.7inch Lcd 200mhzUS$ 420 - 450MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
TONGHUI
Model Number
TDO3062BS
HOT SALE! 20MHz, 1Gsa/s,Multi Triggering Modes Cursor Measurement Digital Storage Oscilloscope Tonghui TDO3062BS
PRODUCT DESCRIPTION
Brief description
TDO3062BS digital storage oscilloscopes provide you with excellent performance and strong functions in a compact design. Even as a new generation of portable low-priced general product, the series still offers many measurement functions of middle or high end product and meets your measurement requirement with affordable cost. With bandwidth of 60MHz, the series offers a maximum real-time sample rate of 1Gsps and equivalent sample rate of 50Gsps to ensure you accurate observation of signal details. Many standard advanced features such as multi triggering modes, cursor measurement functions, auto measurement, digital filtering, waveform storage, math function, FFT, PASS/FAIL judgement, multi communication interfaces, etc. make the measurement faster and easier| Product Model: | TDO3062BS | ||||||
| Sine signal feature | |||||||
|
|
||||||
| Amplitude feature | |||||||
| Amplitude setting range (Hi-resistance) | Output frequency≤20MHz,amplitude range 2mVpp--20 Vpp when >20MHz,amplitude range 2mVpp—6.32 Vpp |
||||||
| Max.Resolution(Hi-resistance) | 2μVp-p | ||||||
| Amplitude deviation | ≤±2%+1mV (1KHz sine wave) | ||||||
| Amplitude stability | ±2 % /4 hours | ||||||
| Amplitude flatness | ≤ 50 kHz ±5% > 50kHz ±20% |
||||||
| Output impedance | 50Ω | ||||||
| AM Modulation feature | |||||||
| Carrier | Sine wave,square wave | ||||||
| Modulation wave | 30 common waves:Sine wave,square wave,triangle wave.etc | ||||||
| Modulation wave frequency | 1mHz--1MHz | ||||||
| Modulation depth | 0% ~ 120% | ||||||
| FM Modulation feature | |||||||
| Carrier | Sine wave and square wave | ||||||
| Modulation wave | 30 common waves:Sine wave,square wave,triangle wave.etc | ||||||
| Modulation frequency | 1mHz--1MHz | ||||||
| Frequency modulation deviation | 0.1% ~ 99.9% | ||||||
| PWM Modulation feature | |||||||
| Carrier | Impulse | ||||||
| Modulation wave | 30 common waves:Sine wave,square wave,triangle wave.etc | ||||||
| Modulation wave frequency | 1mHz--1MHz | ||||||
| Width deviation | 1% ~ 99% | ||||||
| FSK Modulation feature | |||||||
| Carrier | Sine wave | ||||||
| Hop frequency | 1μHz--10MHz | ||||||
| Interval time | 1ms~40s | ||||||
| PSK Modulation feature | |||||||
| Carrier | Sine wave | ||||||
| Hop phase | 0°~360° | ||||||
| Interval time | 1ms~40s | ||||||
| DCOM(Bias modulation)feature | |||||||
| Carrier | Sine wave,square wave | ||||||
| Modulation wave | 30 common waves:sine wave, square wave, triangle wave.etc. | ||||||
| Modulation wave frequency | 1mHz--1MHz | ||||||
| Function | Realize the add function of carrier and modulation wave | ||||||
| Frequency sweep feature | |||||||
| waveform | Sine wave,square wave | ||||||
| Frequency range | 1μHz--10MHz | ||||||
| Sweep type | Forward,backward and round sweep | ||||||
| Sweep time | 1ms~500s | ||||||
| Burst(impulse string) feature | |||||||
| Waveform | 30 common waveforms:sine wave, square wave and triangle wave. | ||||||
| Count | 1~60000 periods | ||||||
| Burst frequency | 1mHz--1MHz | ||||||
