DHT-300 Integrated Leeb Hardness Meter,rockwell hardness tester,hardness gauge,hardness tester
DHT-300 Integrated Leeb Hardness Meter is a portable intergrated Leeb hardness tester which is suitable for the quick hardness test of metal materials. It features high accuracy, reliable performance, easy operation and convenient taking.
Feature & Use:
Pocket size, easy to operate
Based on HL hardness value, conversion can be performed to HRB, HRC, HV, HB, and HS
For most metals
Automatic orientation correction
USB interface for both recharging and data transfer to PC
Internal memory in a batch of 1250 average readings
Lower and upper limits setting with Low-High display judge
Works on 3.7V rechargeable lithium-battery with working more than 16 hours continuously
Auto shutdown after 5 minutes
Conforming to ASTM A 956
Specifications:
Hardness parameter: HL, HRC, HRB, HV, HB, HS
Measuring range / metallic materials: See the table 1
Display: 112×64 LCD with backlight
Display functions D: Impact direction, Battery power consumption, Hardness scale,
Hardness value, Average value, Max/Min value, Material,
Type of impact device
Accuracy Statistics: Within+/- 0.5% (HLD=800)
Testable workpiece:
Thickness coupled: Minimum 3 mm or more (Except with Impact device G:10mm)
Mass: 5kg or more (2-5kg on solid support ,2kg with couplant paste)
Surface roughness: Ra 10
Radius (convex/concave): Rmin=30mm or more (30mm with support ring )
Test Points: 5mm or more from the edge of the sample,
3mm or more to each of the tested points
Memory: 1250 groups
Output: USB port
Impact device (standard): D
Optional Impact Device: DL / C
Power: 3.7V rechargeable lithium-battery with working more than 16 hours continuously
Operating temperature: -20°C ~ +40°C
Overall dimensions: 158x41x26mm (6.3x1.6x1.03 inch)
Weight: 120g / 0.27lb
