ADVANTAGES
1.Wide measuring range. Based on the principle of Leeb hardness testing theory. It can measure the Leeb hardness of
all metallic materials.
2.Large screen LCD, showing all functions and parameters. With EL background light.
3.Seven impact devices are available for special application. Automatically identify the type of impact devices. Test at
any angle, even upside down. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL.
4.Large memory could store 100 groups (Relative to average times 32~1 ) information including single measured
value, mean value, impact direction, impact times, material and hardness scale etc.
5.Battery information showing the rest capacity of the battery and the charge status. User calibration function.
6.Software to connect to PC via USB port. Thermal printer integrated, convenient for in field printing. NI-MH
rechargeable battery as the power source. Charge circuit integrated inside the instrument.
7.Continuous working period of no less than 150 hours (EL off and no printing). Auto power off to save energy.
8.Outline dimensions:212m ×80mm×32mm
MAIN APPLICATION
No. |
Type of impact device |
Hardness value of Leeb standard hardness block |
Erro of displyed value |
Reapeatability |
1 |
D |
760±30HLD 530±40HLD |
±6 HLD ±10 HLD |
6HLD 10HLD |
2 |
DC |
760±30HLD 530±40HLD |
±6 HLDC ±10 HLDC |
6HLD 10HLD |
3 |
DL |
878±30HLD 736±40HLD |
±12 HLDL |
12HLDL |
4 |
D+15 |
766±30HLD 544±40HLD |
±12 HLD+15 |
12HLD+15 |
5 |
G |
590±40HLD 500±40HLD |
±12 HLG |
12HLG |
6 |
E |
725±30HLD 508±40HLD |
±12 HLE |
12HLE |
7 |
C |
822±30HLD 590±40HLD |
±12 HLC |
12HLC |
Measuring range HLD170~960 HLD
Measuring direction 360°
Hardness Scale HL HB HRB HRC HRA HV HS
Display segment LCD
Data memory 100 groups
max. relative to impact times 32~1
Printing paper: width is 57.5±0.5 mm, diameter is 30mm
Battery pack: 6V NI-MH Battery charger: 9V/500mA
Continuous working period about 150 hours With backlight off, no printing
Communication interface USB1.1
Outline dimensions 212mm×80mm×32mm
CONFIGURATION
|
No. |
Item |
Quantity |
Remarks |
Standard Configuration |
1 |
Main uni |
1 |
|
2 |
D type impact device |
1 |
With cable |
|
3 |
Standard test block |
1 |
|
|
4 |
Cleaning brush (I) |
1 |
|
|
5 |
Small support ring |
1 |
|
|
6 |
Battery Charger |
1 |
9V 500mA |
|
7 |
Paper for printing |
1 |
|
|
8 |
Manual |
1 |
|
|
9 |
Instrument package case |
1 |
|
|
Optional Configuration |
11 |
Cleaning brush (II) |
1 |
For use with G type impact device |
12 |
Other type of impact devices and support rings |
|
Refer to Table 3 and Table 4 in the appendix. |
|
13 |
DataPro software |
1 |
|
|
14 |
Communication cable |
1 |
|
|
15 |
|
|
|
|
16 |
|
|
|
