Extruded Magnesium Ribbon Sacrificial Anode
Ribbon type magnesium sacrificial anode is produced by high quality and high purity magnesium, complying with the standards ASTM97-98, GB/T17731-2004, SY/T0019-97.Being extruded and processed by specific technology, the anode has excellent electrochemical performance with flat shape, and adjustable and bendable length.
The extruded ribbon magnesium anode has a larger area mass ratio, so it can produce a greater current than the conventional casting anode. These characteristics can enable it to have the unique application in cathode protection engineering, especially in long distance pipeline. Pipeline crossing, large storage pipe,through the pope section, a large storage tank bottom, for preventing lightning grounding grid and composite anode short anode and so on.
Ribbon Magnesium anode is mainly used to protect a winding body and high resistivity elecrolyte tanks or other steel structure protection, or the construction of the narrow space of the surface, and high resistivity soil and fresh water medium.
Implementing Standards
ASTM97-98
GB/T17731-2004 Magnesium Alloy Sacrificial Anode
SY/T0019-97 Design Codes for Cathodic Protection of Sacrificial Anode for Buried Steel Pipeline.
Main Performance
1.Flat in shape and its length can be adjusted and easy to be bent;
2.Having good corrosion resistance without adding extra DC power supply;
3.Automatic operation after the installation;
4.No need for maintenance;
5.Less land occupation, needing low engineering cost;
6.Not occurring any interference with the external environment
Application
Used for high resistivity environment, casting pipe protection, temporary cathodic protection for pipeline, storage tank and protection for pipe network, anti-electromagnetic interference grounding grid.
Product Specifications of Magnesium Ribbon
Extruded Magnesium Ribbon Sacrificial Anode
Magnesium Ribbon Sacrificial Anode
Magnesium Ribbon Anode
Extruded Ribbon Magnesium Alloy Sacrificial Anode
D Type High Potential Magnesium Anode
Magnesium Alloy Anode for Oil Well Casing
Prepackaged Magnesium Alloy Sacrificial Anode
Magnesium Alloy Sacrificial Anode
Bolt Connection Type Sacrificial Anode
Aluminium Alloy Sacrificial Anode
Zinc Alloy Sacrificial Anodes
Impressed Current Anodes
BV
DNV
1.Quality Assurance
All our products are strictly manufactured in accordance with the production standards. Before being issued the product quality certification, all products are inspected and accepted by the technical inspection department of the manufacturing plant.
2.Product Customization Service
Our company can supply both standard and non-standard products to meet your various needs. We can customized products according to your drawings.
3.Providing Classification Society Certificates
We can supply various certificates of Classification Societies: CCS, ABS, BV, DNV, GL, LR, NK, KR, RINA, RS etc..
4.Excellent Pre-sale and After-sale Service
Our salesmen are adhering to the trading principles of being honest and trustworthy, fair and equitable to provide excellent and satisfactory service for our customers.
