NEW LTC-3X Microcomputer Temperature Controllers for kitchen refrigerator
NEW LTC-3X Microcomputer Temperature Controllers for kitchen refrigerator
Product Overview:
Especially designed for Refrigerant kitchen refrigerator,
Refrigerant cabinet, direct-cooling and air cooled kitchen cabinet,
cake cabinet with stainless panel.
Features:
Temperature setting by wave-band switch konb,visual panel display,easy to operate. Flame retardant material,fully sealed rear shell,the front panel with polycarbonate material,water-proof level up to IP65 Relay output 30A,could drive single-phase compressor 1.5HP or lower,internal placed,convenient for user to install. LTC-3X with the function of defrost after the compressor stops LTC-2X without the function of defrost after the compressor stops.
Parameter:
|
Specification: Mounting size: 112(W) * 39(H) (mm) Product size: 137(W) * 56(H) * 69(D) (mm) Technical parameters: Power supply: 220VAC±10%, 50/60HZ Temperature measuring range: -40~+90℃ (Different specification and series of controllers have different temperature controlling range) Resolution: 1 Accuracy: ±1℃ Compressor, defrost output contact capacity: 30A/240VAC (the max load can drive is 1.5HP) Sensor type: NTC, 2M Temperature controlling level: 0-7 level (OFF is to close controller) Shell: gray ABS flame retardant material |
