600-300 Roof Roll Forming Machine or Steel Sheet Roll Forming Machine

600-300 Roof Roll Forming Machine or Steel Sheet Roll Forming Machine thumbnail-1
600-300 Roof Roll Forming Machine or Steel Sheet Roll Forming Machine photo-1
US$ 30,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Tile Forming Machine, roll forming machine
Tile Type:
Steel
Contact Supplier Request Quote Chat Now
Yingkou Professional Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Tile Forming Machine, roll forming machine
Tile Type Steel
Use Roof
Place of Origin Liaoning, China
Brand Name PR
Model Number PR-120
Power(W) 5.5KW
Voltage 380v
Dimension(L*W*H) 8900mm*2000mm*2400mm
Weight 10T
Certification CE
Warranty 13 months after B/L date
After-sales Service Provided Engineers available to service machinery overseas



600-300 arch sheet roll forming machine

600-300 roof roll forming machine or Steel sheet roll forming machine600-300 roof roll forming machine or Steel sheet roll forming machine

nical parameters

Main Technical Specification:
Size: 8900mm×2000mm×2400mm
Total weight: About 10000KG
Controlling system: PLC (Ormon)
Cutting material: Cr12mov
Main motor power:5.5KW
Bending power: 3.0KW+1.5KW
Cutting power: 3.0KW
Sewing power: 1.1KW+1.1KW
Feeding Width: 600mm
Effective Width:300mm
The depth of the groove:100mm
Sheet operating factor: 50%
Largest Span: ≤35m
Ship Container: 40’GP x 1

file

600-300 roof roll forming machine or Steel sheet roll forming machine

3. arch roof project



600-300 roof roll forming machine or Steel sheet roll forming machine

4.Model list of PR Roll Forming Machine:



Model

Feeding

width

(mm)

Effective

width

(mm)

Depth of

groove

(mm)

Utilization

ratio

Thickness of

steel coil

(mm)

Largest

span (m)

BH-600-300

600

300

100

50%

0.6-1.5

30

BH-600-305

600

305

109

50.8%

0.6-1.5

28

BH-914-400

914

400

210

43.7%

0.6-1.5

40

BH-914-610

914

610

203

66.7%

0.6-1.5

38

BH-914-650

914

650

181

71.1%

0.6-1.5

26

BH-914-700

914

700

123

76.5%

0.6-1.5

22

BH-914-750

914

750

180

82%

0.6-1.5

14

BH-1000-610

1000

610

243

61%

0.6-1.5

42

BH-1000-680

1000

680

223

68%

0.6-1.5

38

BH-1000-700

1000

700

175

70%

0.6-1.5

30

BH-1000-750

1000

750

138

75%

0.6-1.5

24

BH-1000-800

1000

800

114

80%

0.6-1.5

18

BH-1200-800

1200

800

265

67%

0.6-1.5

40

BH-1220-800

1220

800

355

66%

0.6-1.5

42

BH-1250-800

1250

800

320

64%

0.6-1.5

45

5.Working flow:

    Decoiler-----feeding------roll forming ------pressing----- cutting----output table
