Product Name: Galvanized Steel Strip
• Steel grade: DX51D+Z
• Zinc coverage: 60-2000 g/sqm on both sides (depending by the requested specification)
;• Thickness: between 0,2 mm and 1,00 mm;• Width: 600mm,914mm,1000mm, 1220mm and 1250 mm;
• Coil weight: 4-6 mt;• Coil ID: 508 mm;
• Coil OD: 900-1500 mm ;
Depending on their usage, the hot-dip galvanized coil can be delivered slightly oiled.
Surface Treatment |
Features |
Chemical passivating treatment |
minimize the chance of white rust forming during transit and storage |
maintain the bright, shiny appearance for a longer time | |
Oils |
minimize the tendency for storage and transit stain |
Passivating oils |
provide the protection from storage and transit stain by special chemicals called corrosion inhibitors |
Surface Finish of Hot Dip Galvanized Steel Strip:
Surface finish |
Pattern: |
Application: |
Regular spangle |
Standard spangles with flower pattern |
General uses |
Minimized spangle |
Minimized spangles than regular |
General painting application |
Zero spangle |
Extremely minimized spangles |
Special painting application |
Process of Hot Dip Galvanized Steel strip:
Pay off reel → double cut shear → welder-notcher → entry accumulator → pre cleaning section
→ furnace → hot bridle → zinc pot → air knife → after cooler → water quench
→ dryer → skin pass mill → dryer → tension leveler → dryer
→ chemical coater → chemical oven → cooler → exit accumulator
→ oiler → exit shear → tension reel.
Mill Photo
Certificate
BV
BV
ISO:SGS
Packing Photo
Factory In Africa
Billboard In Bolivia
