Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Packaging Equipment > SZG Series Conical Vacuum Dryer

SZG Series Conical Vacuum Dryer

Name: SZG Series Conical Vacuum Dryer
Brand: yibu
SKU: 131570807

SZG Series Conical Vacuum Dryer thumbnail-1

US$ 230,000 - 890,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

yibu

Model Number:

SZG

Contact Supplier Request Quote Chat Now

Changzhou Yibu Drying Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name yibu

Model Number SZG

Application Powder

Type Drying Machine

After-sales Service Provided Engineers available to service machinery overseas

SZG Conical Vacuum Dryer

SZG Series Conical Vacuum Dryer is a new generation drying device developed by our factory on the basis of combining the technology of similar equipment. It has two connecting ways, i.e. belt or chain. Therefore it is stable in operation. The special design guarantees two shafts realize good concentricity. Heat medium and vacuum system all adapt reliable rotating connector with the technology from USA. On this basis, we also developed SZG-A. It can carry out steeples speed change and constant temperature control.
As a specialized factory in drying industry, we supply hundred sets to the customers every year. As for working medium, it may be thermal oil or steam or hot water. For drying the adhesive raw material, we have designed specially a stirring plate buffer for you.

It is suitable for the raw materials that need to concentrate, mixed and dried at low temperature (for example, biochemistry) products in chemical, pharmaceutical and foodstuff industries. Particularly it is suitable for the raw materials that are easy to be oxidized, volatilized and have night heat sensitivity and is toxic and not permitted to destroy its crystal in drying process.

item		spec
name	unit	100	200	350	500	750	1000	1500	2000	3000	4000	5000
total volume	L	100	200	350	500	750	1000	1500	2000	3000	4000	5000
working volume	L	50	100	175	250	375	500	750	1000	1500	2000	2500
heating area	m 2	1.16	1.5	2	2.63	3.5	4.61	5.58	7.5	10.2	12.1	14.1
speed	rpm	6							5	4	4	4
power	kw	0.75	1.1	1.5	1.5	2	3	3	4	5.5	7.5	7.5
rotating height	mm	1810	1910	2090	2195	2500	2665	2915	3055	3530	3800	4180
total weight	kg	825	1050	1350	1650	1800	2070	2250	3000	4500	5350	6000
design pressure inside the tank	mpa	-0.09~-0.096
design pressure of jacket	mpa	0.3

Speed adjusting motor of 0-6rpm might be chosen according to the user's requirements. The following aspects should be point out when to order:
1. The above-mentioned parameters are calculated based on material density of 0.6g/cm3. If it's over, please point out.
2. If certificate for pressure vessel is required, please point out.
3. If glass lining for interior surface is required, please point out.
If the material is explosive, or flammable, the calculation should be made according to trial result.

When oil is used to heat, use automatic constant temperature control. It can be used for drying biology products and mine. Its temperature of operation can be adjusted form 20-160 °C .
Compared to ordinal dryer, its heat efficiency will be 2 times higher.
The heat is indirect. So the raw material can not be polluted. It is in conformity with the requirement of GMP. It is easy in washing and maintenance.
