14.4W 72 Leds RGB Double Row 2835 Epistar Strip

14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-1
14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-2
14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-3
14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-4
14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-5
14.4W 72 Leds RGB Double Row 2835 Epistar Strip thumbnail-6
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-1
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-2
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-3
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-4
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-5
14.4W 72 Leds RGB Double Row 2835 Epistar Strip photo-6
US$ 1 - 2 MOQ: 1 Meter
Key Specifications
Get Latest Price
LED Light Source:
2835 epistar strip
Type:
Flex LED Strips
Input Voltage(V):
DC12V
Contact Supplier Request Quote Chat Now
Shenzhen Ouge Star Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 2835 epistar strip
Type Flex LED Strips
Input Voltage(V) DC12V
Lamp Power 14.4W/M
Lamp Luminous Flux(lm) 1800
Color Temperature(CCT) 2700-11000K
Working Temperature(℃) -20, 55
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name Star
Model Number 2835 epistar strip

14.4W 72 leds RGB double row 2835 epistar strip



Why us

14.4W 72 leds RGB double row 2835 epistar strip

  • 1.All of OUGE STAR products under the hl-tech corporation standard production
  • 2.CEROHS FCC Approved
  • 3.Promise made promise delivered
  • 4.Serve professionally
  • 5.No lowest price but always value for money





Product Description

14.4W 72 leds RGB double row 2835 epistar strip

Function:



  1. Brand: STAR
  2. Chip:   Taiwan Epistar 2835
  3. LEDs: 72leds/m
  4. Voltage: DC12/24V (12V in default)
  5. Power: 14.4w/m,
  6. Working current: 0.8A-1.2A
  7. Light color: RGB/White/warm white/red/blue/green/yellow/cool white
  8. Viewing angle: 120°
  9. Storage temperature: -40 ~ +80
  10. Operating temperature: -25 ~ +60
  11. Certificate: CE, RoHS
  12. Width: 5mm
  13. 2835: 3LEDs-cuttable at marked intervals
  14. Connect quickly with connectors
  15. Match the suitable power supply and remote controller
  16. 3m self-adhesive or matched mounting clip for easy stallation
  17. Warranty: 3 years


Features:

  • Can be able to do combination colours and dimmed
  • Low power consumption,Super-bright but running with low temperature
  • All the light spread and completely smooth,luminous very even
  • Every 3-LEDS cuttable without damaging the rest strips, according to your requirement
  • Self-adhesive back with Adhesive tape for secure and easy application
  • Dc-plug already soldered on the connector, ready to be plugged in and working
  • LED Type: High Quality 5050 SMD LED, high intensity and reliability, Long lifespan >50,000 hours

 Specification:



Item Name:

14.4W 72 leds RGB double row 2835 epistar strip

Chip:

smd 2835

Brightness:

20-22lm/led

LEDs:

72leds/m

Power:

14.4W/m

Voltage

DC12V DC24V

Cuttable

every 3 LEDs

Material:

FPC

Light beam:

120

CRI:

Ra 80

Unit

1/5/10/20M/reel

Color:

option

IP Rate

IP20 IP65 IP66 OPTION

Warranty:

3YEARS

Certificate:

CE,RoHS





Notes:

1. Make sure the connection is correct according to the diagram.
2. Pay attention on the parameters limit on the above form. DO NOT run over the peak value.
3. Keep the surface of installation clear and level avoid breaking off. c
4. Avoid the crook area is the just the position of LED and other components, in order to protect the product and extend the life span of the product.
5. in installation please note that led strips the article input and output port .
6. when a current in please make sure the input voltage for the article lamp whether DC12V/ DC5V .
7. the outdoor when using note, the led strips of article exterior waterproofing if there is any breakage.





Application:
Widely used for home decoration use, hotels, clubs, shopping malls
Architectural decorative lighting, boutique atmosphere lighting
Extensively applied in Backlighting, concealed lighting, channel letter lighting
Emergency & security lighting, advertisement sign lighting
Decorative lights for holiday, event, show exhibition
Applicable for automobile and bicycle decoration, border or contour lightin





14.4W 72 leds RGB double row 2835 epistar strip14.4W 72 leds RGB double row 2835 epistar strip14.4W 72 leds RGB double row 2835 epistar strip14.4W 72 leds RGB double row 2835 epistar strip

14.4W 72 leds RGB double row 2835 epistar strip 14.4W 72 leds RGB double row 2835 epistar strip
 14.4W 72 leds RGB double row 2835 epistar strip

    14.4W 72 leds RGB double row 2835 epistar strip

    14.4W 72 leds RGB double row 2835 epistar strip
14.4W 72 leds RGB double row 2835 epistar strip

  14.4W 72 leds RGB double row 2835 epistar strip
14.4W 72 leds RGB double row 2835 epistar strip 14.4W 72 leds RGB double row 2835 epistar strip

  14.4W 72 leds RGB double row 2835 epistar strip
