Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp

Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp

Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-1
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-2
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-3
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-4
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-5
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp thumbnail-6
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-1
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-2
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-3
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-4
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-5
Office Using,ultra-thin 54w 36w Flat Led Panel Lighting SMD2835 3014 Led Panels 60*60 Led Panel Lamp photo-6
US$ 34 - 37 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
SMD LED
Warranty(Years):
3
Input Voltage(V):
85-265
Contact Supplier Request Quote Chat Now
Shenzhen Buddy Lighting Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD LED
Warranty(Years) 3
Input Voltage(V) 85-265
Lamp Power(W) 34
Lamp Luminous Flux(lm) 3000
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Other, 3000-5000K
Working Temperature(℃) -20, 40
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP44
Certification C-tick, CE, CQC, EMC, LVD, SAA
Place of Origin Guangdong, China
Brand Name BUDDY
Model Number PL6060-054
Product Description



Trim                                     Aluminum alloy

High light conductivity LGP (PMMA light guide plate,); High light transmittance PVC cover

Size                                       L600*W600*11mm

Beam Angle                         155°

Light Source                       180pcs 2835 high brightness SMD LED(12-14lm per LED )

Input Voltage                       220-240V AC, 50-60Hz ( non dimmable, come with Philips driver )

       200-245 V AC, 50-60Hz ( leading edge, trailing edge and universal dimming )

PF                                         >0.9

Input Power                         34W (nominal)

Color temp.                           2700K-6500K

Luminous Flux                       3000lm in Max.

CRI                                       70+

Operating Temp. Range       -20 to +40 ℃

IP Rating                               IP44,Indoor use only

Storage conditions               Cool and dry place.

Driver                                     Exterior

Maintenance Of Lumens     40,000 hours at 25 ℃

Installation                             Recessed, Ceiling Mounting, Pendant



Office using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lamp







LED Panel Light



1) Working voltage: 85-265V AC, 50-60Hz ( non dimmable) / 200-245 V AC, 50-60Hz ( dimmable )



2) Power consumption: 34W in Max.



3) Lumens: 2245lm in Max.



4) LED q'ty: 180 pcs 2835 high brightness SMD LEDs



5) Size: 600*600*13mm



6) Exterial driver



7) Package: 5pcs per carton







Office using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lampOffice using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lamp

Office using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lamp

Office using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lampOffice using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lampOffice using,ultra-thin 54w 36w flat led panel lighting SMD2835 3014 led panels 60*60 led panel lamp



Send Inquiry to This Supplier

* Message
0/5000

Want the best price? Post an RFQ now!
Shenzhen Buddy Lighting Limited
Business Type
Manufacturer, Trading Company
Year Established
2012
Factory Size
1,000-3,000 square meters
Total Employees
11 - 50 People
Contact Supplier Request Quote Chat Now
