HZ-90 A PET BOTTLE BLOWING MACHINE
2. Price List:
No |
Equipment Name |
Model |
Price |
Qty. |
Amount(USD) |
1 |
Blow molding machine (Two-cavity with two-die) |
BDY702D |
|
1 |
|
2 |
Chiller(Air Cooler) |
5HP |
|
1 |
|
3 |
Crusher |
PC400(10HP) |
|
1 |
|
4 |
Auto loader (AUXILIARY) |
300KG |
|
1 |
|
5 |
Hopper drier (AUXILIARY) |
100KG |
|
1 |
|
6 |
Mixer (AUXILIARY) |
200KG |
|
1 |
|
7 |
MOOG parison system (AUXILIARY) |
|
|
1 |
|
8 |
Leaking tester (AUXILIARY) |
|
|
2 |
|
|
Air system |
||||
9 |
Air Compressor(10HP) |
1m³/min,(0.6-1.0)Mpa |
|
1 |
|
10 |
Air filter |
|
|
1 |
|
11 |
Air drier |
|
|
1 |
|
| |||||
12 |
Die(one cavity for 4L) |
|
|
1 |
|
|
Mould |
||||
13 |
3.78L mould with deflashing device(HC55), one die with one cavities |
|
|
2 |
|
14 |
0.5L-1L mould with deflashing device (HC55), one die with two cavities |
|
|
2 |
|
|
SUM: FOB shanghai: USD |
||||
Note:
1. The item 5~8 is optional device marked in red. Just choose them according to your demands. Without those devices, the system also can run.
2. The material of mould is steel HC55
3. Payment: Prepay: 30% by T/T as deposit; 70% by T/T against the B/L.
4. Delivery time:50 days after receiving the deposit and samples.
5. Capacity: 5L=160-180BPH, 0.5L=950-1050BPH, Voltage: 380V/50HZ
CONFIGURATION:
Touch screen |
HITECH |
Taiwan |
PLC |
MITSUBISHI |
Japan |
Transducer |
MITSUBISHI |
Japan |
Temperature controller |
OMRON |
Japan |
Low pressure electrical |
Schneider |
France |
Relay |
Schneider |
France |
Button switch |
Schneider |
France |
Electricity machine |
SIEMENS/Beide |
Germany |
electronic rule |
GEFRAN |
ITLAY |
Contactor |
Schneider |
France |
Oil pump |
YUKEN |
Japan |
Hydraulic pressure valve |
YUKEN |
Japan |
Pneumatic component |
FESTO |
Germany |
