Help CenterCP-60 Current Probe
Related Products
Specifications
The current probe CP-60 is designed to measure current up to 60A with high frequency response.The current probe CP-60 is designed to measure current up to 60A with high frequency response. One of the most important applications is to monitor the transient current to drive solenoids of diesel electronic .
CP-60 can be connected to an oscilloscope to monitor the detailed current waveform of diesel fuel injection, such as injection timing, maximum current, injection duration, and multiple injection, which are crucial to diagnose the operational problems of electronic diesel engines for engineers and technicians in the engine development labs and repair shops as well.
Design Features
Frequency response up to 20KHz, capable of monitoring the dynamic characteristics of drive current for electromagnetic valves on electronic diesel engines
Two levels of output gains, 100mV/1A and 10 mV/1A
Maximum measured current 60 A
Zero adjustment is made easy by just pushing the ZERO button
Small jaw size to fit into tight space in wire bundle
With a BNC connector, it is able to be connected to an oscilloscope to monitor current waveform
