Specifications
EUI/EUP Cambox Fixture EUS-1000 includes 1 electronic controller, 1 mechanical cam box, 4 camshafts, specified EUI/EUP adapters
EUI/EUP Cambox Fixture EUS-1001 is designed to perform repair tests for various types of EUIs and EUPs of all major brands on the market by FIEs and engine manufacturers. The fixture is carefully designed to make the system simple and easy to use.
The EUS-1000 package includes one electronic controller EU-1001, one mechanical cambox CB-1000, four (4) camshafts with different lifts, and specified EUI/EUP adapter kits to test all EUIs and EUPs. The cam box is designed to be driven by a standard high pressure fuel injection pump test bench.
Design Features
1. Four camshafts with four (4) levels of lift and constant cam velocity
2. Cam box mounting height 125mm (from the center of camshaft to bench mounting platform);
3. A speed sensor installed on the cam box for injection synchronization;
4. Feed back controlled and modulated driving current signal to ensure proper fuel injection of EUI/EUP, regardless of its solenoid characteristics;
5. User adjustable start of injection (SOI) angle and pulse width of solenoid driving signal;
6. Short circuit protection for the output circuitry of the solenoid driving signal;
7. Adapters for most EUIs/EUPs on the market, including
Bosch, Delphi, Cummins, CAT, Mercedes Benz, Detroit Diesel, MTU, Freightliner, Volvo, Scania, Iveco, DAF, Landrover, Renault, Deutz, Volkswangan.
