With more excellent design, more powerful strike and much lower price, EDT 2000 is your best option for your excavator from18-26ton.
Besides EDT2000 Hydraulic Breaker , we can offer you : EDT100/EDT200/EDT300/EDT400/EDT430/EDT450/EDT800/EDT1600/EDT2200/EDT3000/EDT3200/EDT3500/EDT4500. to suit Excavator,backhoe loader, skid steer loader ranging from 0.8ton to 70ton
16 models from EDT100 to EDT2000, EDT4500 hydraulic breaker/hydraulic rock breaker/rock breaker/hydraulic hammer can be suited all the makes and models of Excavators, backhoe loaders,
including, Cat, Case, JCB, Komatsu, Hitachi, Daewoo, Doosan, Volvo, Kobelco, NEW HOLLAND, Terex, Sumitomo, Libeheer, Yanma, SANY, XCMG, XG, LG, Liugong, Yuchai, Hyundai, Jonyang, Liugong, Johndeer, Kubota, Bobcat, Takeuchi, IHI, Samsung, Kato, etc.
| Model | EDT2000 | |
| Specification | Unit | |
| Body weight | kg | 840 |
| lbs | 1851 | |
| Total weight | kg | 1818 |
| lbs | 4008 | |
| Length | mm | 2835 |
| inch | 116 | |
| Hydraulic oil pressure | kg/cm2 | 160-180 |
| psi | 2272-2556 | |
| bar | 157-178 | |
| Hydraulic oil flow | l/min | 130-150 |
| gal/min | 34.3-39.6 | |
| Impact frequency | bpm | 400-800 |
| Hose diameter | mm | 25.4 |
| inch | 1 | |
| Chisel diameter | mm | 135 |
| inch | 5.3 | |
| Chisel weight | kg | 119 |
| lbs | 262 | |
| Applicable bucket capacity | m3 | 0.7-0.9 |
| Applicable vehicle weight | ton | 18-26 |
| Impact power | ft-lbs | 2646 |
| Joule | 3588 | |
| Main valve type | Outward | |
| Accumulator | Yes | |
| Accumulator pressure | kg/cm2 | 60±0.5 |
| Nitrogen pressure | kg/cm2 | 16.5 |
