Help CenterCRS-B Common Rail Tester With Flow Meter
Related Products
Specifications
CRS-B Common Rail Tester is upgraded from CRS-A by adding a digital fuel flow meter.CRS-B Common Rail Tester is upgraded from CRS-A by adding a digital fuel flow meter. CRS-B is able to test all kinds of common rail fuel injection injectors and pumps by Bosch, Delphi, Denso and Siemens.
CRS-B is aimed to upgrade a traditional diesel high pressure pump test bench and replace the attached fuel metering glass graduates to a full functioned automatic equipment for all tests of repairing common rail injectors, pumps or CR systems.
CR Injector Drivers
6 solenoid injectors
High voltage for Bosch, Denso injectors
Low voltage for Delphi injectors
4 piezoelectric injectors, made by Siemens, Bosch
Short circuit protection for both solenoid and piezo injector drivers
CR Pump Drivers
Multiple independent PWM (Pulse Width Modulation) output channels to drive pump solenoids
Testing pumps with single regulation valve
Bosch CP1/CP2/CP3
Delphi CRSP
Denso HP3/HP4
Testing Siemens DCP pump with two regulation valves
Drive 3 DRVs for testing pump capability
2 special output channels synchronous with pump speed to drive the two control solenoids on Denso HP0 (ECD-U2)pump
Fuel Rail Pressure Sensor
Pre-calibrated for Bosch, Delphi, Denso pressure sensors
User calibrateable for different pressure sensor
Automatic rail pressure control
Software based over-pressure protection
User Interface
Touch screen with a simple 4-key panel
User friendly multi-language interface
User manageable test database
Standard keyboard and mouse
USB port or standard SD card port for system software upgrade, a USB memory stick is included in the package
6 LED to indicate injector status
Standard VGA port for external large screen display
Fuel Flow Meter
To be installed easily on the swing arm of a pump test bench to replace the glass graduates
Gear meter, imported from Germany
8 measurement channels
User definable channel connection
Automatic fuel flow measurement for testing common rail injectors or pumps
Service and Accessories
One year manufacture warranty
One year software free upgrade
Injector and pump test procedure and database
DRV adaptor for pump flow rate test (Optional)
Rich accessories
Matching supporting cabinet with 4-wheels (Optional)
