Help CenterCheap!!! PVC Coated Gabion Box(SGS FACTORY)
Related Products
-
Factory of Gabion Basket/welded Gabion Box(ISO9001 MANUFACTURER)US$ 5.5 - 28.7MOQ: 10 Units -
Super High Quality Welded Gabion Basket/Welded Mesh Gabions(SGS FACTORY)US$ 9.5 - 39.5MOQ: 10 Units
-
Galvanized/Aalfan/pvc Coated Gabion Box/basket(Best Price)US$ 8.05 - 35.45MOQ: 10 Units
-
Best Seller!!!Hexagonal Gabion Basket Gabion Mesh(Direct Factory)US$ 12.5 - 38.6MOQ: 10 Units
-
Top Selling!!!Welded Steel Gabion Basket for Sale(SGS FACTORY)US$ 18 - 45MOQ: 10 Units
Specifications
1)We have passed ISO9001 Quality System Certificate2)Competitive price
3)Best Quality
4)Various specification
PVC Gabion Box& Plastic gabion basket&gabions price (Factory producing)
1.Diamond design and supply gabion boxes made of heavy hexagonal wire nettings.
2.Gabions sizes: 2X1X1m, 3X1X1m, 4X1X1m, 2X1X0.5m, 4X1X0.5m, 6X2X0.3m ect, or Custom orders available.
3.We have rich experience of exporting kinds of hot-dipped galvanized, galvanized aluminum alloy or PVC coated gabion etc.
Specifications of the PVC Gabion Box
Opening |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coate)/ Inner/Outside(mm) |
Strands |
60X80 |
φ2.0-2.5 |
φ2.0/3.0-2.5/3.5 |
3 |
80X100 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
80X120 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
100X120 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
100X150 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
120X150 |
φ2.0-4.0 |
φ2.0/3.0-3.0/4.0 |
3 |
The production's material and size can be producted as the customoer's requirement.
Technical standard of the PVC Gabion Box
1) All the gabion mesh/wire/box sizes specifications according to ASTMA975.
2) Zinc-Coated SteelWire as perASTM_A641, Class 3 Coating, soft temper.
3) PVC (Polyvinyl Chloride) Coated, Ho gabion rock t-dip Galvanized First.
4) Zn - 5Al - MM Coated SteelWire as perASTMA 856/A 856M, Class 3 coating, soft temper
5) PVC Coating requirements according to ASTM Standard and EN 10245-2 Standard.
Sizes of the PVC Gabion Box
|
Typical Gabion and Mattress Sizes (SI Units) | |||
Length |
Width |
Height |
Diaphragms |
Meter |
Meter |
Meter |
Each |
2.0 |
1.0 |
0.3/0.5/1.0 |
1 |
3.0 |
1.0 |
0.3/0.5/1.0 |
2 |
4.0 |
1.0 |
0.3/0.5/1.0 |
3 |
3.0/4.0/6.0 |
2.0 |
0.17/0.23/0.3 |
2/3/5 |
Features of the PVC Gabion Box
1.Economic: Just fill the stone into the gabions and seal it.
2.Simple installation: No special technology needed.Weather proof under natural destroy, corrosion resistant. No collapse even under big scope of deforming.Sludge in the stones is good for plant growing.Mixed to form a integrity with the natural environment.Good permeation can prevent the damage by hydrostatic.
3.Less transport freight: It can be folded together for transport and further installation.
If you have any questions,please don't hesitate to contact me.
