Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Engineering & Construction Machinery Parts > YCW-B Light Jack

YCW-B Light Jack

US$ 300 - 3,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

YCW

Model Number:

YCW60B-900B

Contact Supplier Request Quote Chat Now

Tianjin Zhenhua Prestressing Force Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJIN PORT

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name YCW

Model Number YCW60B-900B

1.Application

Using for pulling the YM anchor group as well as other type anchorages,through changing the different accessories,it can also be used for DM upset head anchorage and casting anchorage,so it has been widely used in pre-tension working tasks.

2.Usage&Feature:

YCW-B series jacks are light core-through jacks with multifunction

which fit for various anchorages in prestressing tension operation.

The device can be utilized widely in post-tensioning operation for

immense constructions, structures, prestressed concrete bridges,

ground anchorage, marine constructions, foundation anchorage,

etc.

YCW-B series jacks are advanced devices based on their

former structures of YCW, redesigned with high-strength steel,

advanced structures, sealing function, optimization technology.

This new type features tight structure, lightened weight, short

axial length, strands saving by short reserved length in prestressing

strand anchorage. The result of test shows its perfect performance,

durability, flexibility of lifting, convenience of using and repairing.

3.Parameters of YCW Jack

TYPE	YCW60B	YCW100B	YCW150B	YCW200B
MPa Nom. pressure	52	51	50	53
Tensile Piston Area	1.15×10-2	1.908×10-2	3.022×10-2	3.768×10-2
KN Nom. Tensile Force	598	973	1511	1997
Return Piston Area	0.41×10-2	0.78×10-2	1.609×10-2	2.17×10-2
mm Tensile Stroke	200	200	200	200
MPa Return Pressure	≤25	≤25	≤25	≤25
mm Cavity Aperture	Ø58	Ø78	Ø100	Ø120
Kg Weight	46	64	110	144
mm Over Size D×L	Ø175×357	Ø216×363	Ø280×363	Ø315×363

TYPE	YCW250B	YCW300B	YCW350B	YCW400B
MPa Nom. pressure	51	52	52	50
Tensile Piston Area	4.836×10-2	5.77×10-2	6.78×10-2	7.913×10-2
KN Nom. Tensile Force	2466	3000	3526	3956
Return Piston Area	2.802×10-2	3.13×10-2	3.46×10-2	4.592×10-2
mm Tensile Stroke	200	200	200	200
MPa Return Pressure	≤25	≤25	≤25	≤25
mm Cavity Aperture	Ø130	Ø146	Ø165	Ø165
Kg Weight	164	217	265	284
mm Over Size D×L	Ø350×365	Ø385×373	Ø416×392	Ø440×392
(TYPE)	YCW500B	YCW650B	YCW800B	YCW900B
MPa Nom. pressure	49	49	51	54
Tensile Piston Area	10.05×10-2	13.13×10-2	15.83×10-2	16.58×10-2
KN Nom. Tensile Force	4926	6434	8073	8952
Return Piston Area	4.77×10-2	6.29×10-2	9.04×10-2	8.72×10-2
Tensile Stroke(mm)	200	200	200	200
Return Pressure ( MPa )	≤25	≤25	≤25	≤25
Cavity Aperture(mm)	Ø196	Ø240	Ø260	Ø280
Weight(KG)	444	617	950	1120
Over Size D×L(mm)	Ø495×445	Ø575×455	Ø650×530	Ø670×575
