Specifications
Our patented wet lime dust collector widely applies in lime plant, iron works, power plant and chemical industry.Main principle and advantages
Dust and steam enter dust removal water cabin though dust cage and dust pipe. After complete treating with the dust, discharge clean gas from the vent. During solving dust and steam, water in cabin turns out hot slime water by absorbing dust and steam, then via high pressure pump, throwing into pipes for cycling usage in the water system.
Advantages
1. Realize the cycling usage of water and the reuse of overflow dust
Recycle waste heat of hot steam which can improve the hydrating rate , save energy ,solve the dust pollution problem and raise working efficiency finally
Technical parameters:
1. Dust collecting rate:up 99%
Dust removal effect: Dustiness at the vent of dust collector is less than 30 mg/m3
2. hydraulic pressure: >3kg
This device is upgraded product which developed on the base of our original dust removal device. No matter change water or not, it is able to run. So the range of application is wider. The dust extraction ratio can reach 99%.
This device taken the techniques of dust labyrinth circulation and fluid dynamics. Its able to balanced allocate the effective wind produced by blower-fan into the internal dedusting pipes. So that all the steam and dust produced during the process of quicklime hydration could be balanced disposed and filtered by the high pressure spray and water in tank. And all the filtered water and dust flow back to hydrating cabin. it will achieve the aim of water recycle and environment protection.
