Specifications
power drive nverter1 Optimize VF Control
2 Support Modbus Protocol
3 Intelligently control cooling fan start/stop inverter
power drive inverter
FR100-2T-0.4B-E
Variable-frequency Drive VFD Inverter 0.37kw
FR100 Series multifunction inverter is a compact, feature-rich, and highly price-competitive
models.Particularly suitable for electronic equipment, food packaging, woodworking, treadmills and
other small power transmission applications.
It has the following main features:
-Optimized VF control
-Internal simple EMC filter
-Track-mounted design
-Characteristics of the uploading and downloading module for choosing
-MODBUS communication supported
-According to the temperature of the inverter to intelligent
control the cooling fan start or stop
-The maximum output frequency reaches 600.00Hz
- Four deceleration time for selecting
-Operation mode selectable when warning
-Support count control and fixed length control
-Quick release design when Cleaning or replacing the fan
- Keyboard potentiometer control
-Output short circuit protection
- With one high-speed pulse input
-Support PID,16-segment multi-speed,The program runs,Wobbulation operating
FR100 Series Electrical Specifications
Model No. |
Powercapacty kVA |
Rated input current (A) |
Rated output current (A) |
Motor PowerMotor Power kW HP |
|
1-Phase:220V,50/60Hz | |||||
FR100-2S-0.2B |
0.5 |
4.9 |
1.6 |
0.18,0.2,0.25 |
0.25 |
FR100-2S-0.4B |
1.0 |
6.5 |
2.5 |
0.37,0.4 |
0.5 |
FR100-2S-0.7B |
1.5 |
9.3 |
4.2 |
0.75 |
1.0 |
FR100-2S-1.5B |
3.0 |
15.7 |
7.5 |
1.5 |
2 |
FR100-2S-2.2B |
4.0 |
24 |
9.5 |
2.2 |
3 |
3-Phase:220V,50/60Hz | |||||
FR100-2T-0.2B |
0.5 |
1.9 |
1.6 |
0.18,0.2,0.25 |
0.25 |
FR100-2T-0.4B |
1.0 |
2.7 |
2.5 |
0.37,0.4 |
0.5 |
FR100-2T-0.7B |
3.0 |
4.9 |
4.2 |
0.75 |
1 |
FR100-2T-1.5B |
4.0 |
9.0 |
7.5 |
1.5 |
2 |
FR100-2T-2.2B |
6.0 |
11 |
9.5 |
2.2 |
3 |
3-Phase:380V,50/60Hz | |||||
FR100-4T-0.7B |
1.5 |
3.4 |
2.5 |
0.75 |
1 |
FR100-4T-1.5B |
3.0 |
5.0 |
4.2 |
1.5 |
2 |
FR100-4T-2.2B |
4.0 |
5.8 |
5.5 |
2.2 |
3 |
FR100-4T-4.0B |
6.0 |
11 |
9.5 |
3.7,4 |
5 |
