16 Port Full Gigabit Ethernet Switch
introduction
SW1600G is a 16 port full gigabit ethernet switch,supply 16*10/100/1000Mbps GE port,it can be applied to IPC camera, Wireless AP, and IP Phone, and easy for network transmission.
Main Features
16GE, 500M CPU, 52G bus.
Memory Forward: 4.1M
Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab.
Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.
Auto MDI/MDIX.
Upstream port lightning protection.
Store-and-forward.
All ports support wire speed switch, jumbo frame transmission.
Zero QFD, self-adaption.
Panel lights can monitor operative mode and malfunction analysis.
Specification
Model |
SW1600G |
|
1000M Rj45 |
16 |
|
|
Function |
Exchange Mechanism |
Store-and-forward |
Exchange Capacity |
52G |
|
MAC |
8K |
|
|
Environmental |
Working Temperature:0℃~40℃ Storage temperature :-40℃~70℃ |
|
|
Working Humidity :10%~90% RH non-condensing Storage Humidity:5%~90% RH non-condensing | ||
power |
AC110-265V 50/60HZ |
|
|
Network protocol |
IEEE 802.3X IEEE 802.3i 10BASE-T X IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T G IEEE 802.3x Flow control IEEE 802.1q VLAN Bridge operation |
|
|
Default Mode |
Common switch |
|
Match |
VLAN isolation |
|
|
Speed |
Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
|
|
Network Media |
10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000Base-T: Pair 4 Category 5 (cat 5e)and above UTP/STP(≤100m) |
|
Physical Specifications |
Product Size:440mm*209mm*45 mm(L*W*H) package Size:497mm*373mm*93 mm(L*W*H) 2.7kg |
|
Product Ordering Information :
Model Number:SW1600G
Product Details:16GE
How to control the quality?
