0.7 Inch Orange Color 5*7 Led Dot Matrix Module

Name: 0.7 Inch Orange Color 5*7 Led Dot Matrix Module
Brand: ATI led dot matrix module
SKU: 132242377

US$ 0.29 - 2.9 MOQ: 1000 Pieces

Key Specifications

Model Number:

SZ3107057

Chip Material:

AlGaInP

Emitting Color:

Orange

ATI Electronics Technology Limited (Wuxi)

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai; Ningbo; Shenzhen and other Mainland ports

Delivery Detail:

Delivery time depends on order quantity.

Model Number SZ3107057

Chip Material AlGaInP

Emitting Color Orange

Luminous Intensity 120Mcd

Luminous Flux(lm) 20

Optical Attenuation(%) 5%

Power 1W

Power Dissipation 0.9

Color Rendering Index(Ra) 80

Color Temperature 603nm

Operating Temperature(℃) -40, 80

Storage Temperature(℃) 20, 25

Place of Origin Jiangsu, China

Brand Name ATI led dot matrix module

Certification CE

ATI LED DOT MATRIX MODULE

Features—Our Products Stand out of Others

1.Over 12 years producing experience as the vendor of Samsung,Haier,LG etc.

2.Big scale of producing makes sure that your purchase cost is lower.

3.Advanced production line guarantees stable quality and long life span.

4.High luminous intensity output, low voltage and current operating, ultra-low power consumption.

5.Solid-state LED Epistar chip based, easy mounting on printed circuit board and sockets.

Product Exhibition—Show the Details for You

ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:

PARAMETER	SYMBOL	TEST CONDITION	Color	MIN	TYP	MAX	UNIT
Forward Voltage ,Per Segment	VF	IF=20mA	orange	1.9	2.0	2.5	V
Reverse Current , Per Segment	IR	VR=5V	orange			50	μA
Peak Emission Wavelength	λp	IF=20mA	orange	600	603	606	nm
Luminous Intensity Per Segment	IV	IF=20mA	orange	100	120	140	mcd
