Triplex ABC Cable---Aerial Bundled Conductor
US$ 0.1 - 5
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HNTDDL
Model Number:
AAC/XLPE
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO/NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Quadruplex Service Drop CableUS$ 0.1 - 50MOQ: 1000 Meters -
Triplex Service Drop Cable-ACSR Conductor for American SizesNegotiableMOQ: 1 Kilometer
-
ABC (Aerial Bounded Cable) IEC SizeNegotiableMOQ: 1 Kilometer
-
Duplex Service Drop /Aerial Bunded CableNegotiableMOQ: 1 Kilometer
-
0.6/1kV ABC Cable- Triplex Service DropNegotiableMOQ: 1 Kilometer
Place of Origin
Henan, China
Brand Name
HNTDDL
Model Number
AAC/XLPE
Insulation Material
Other, PE/XLPE
Type
Low Voltage
Application
Overhead
Conductor Material
Aluminum
Jacket
Other, XLPE
Specifications
Used to supply power,usually from a pole-mounted transformer,to the user's service head where connection to the service entranceTriplex Service Drop.
1.Application
Used to supply power,usually from a pole-mounted transformer,to the user's service head where connection to the service entrance cable is made.To be used at voltage of 600 volts phase-to-phase or less and at conductor temperature not to exceed 75 for polyethylene insulated conductors or 90 for crosslinked polyethylene(XLP) insulated conductors.
2.Construction
| Code*Word | Phase conductor | Bare Neutral Message | Nominal lay Length | Weight Per 1000 ft.(lbs.) |
Allo wable Amp acitles | ||||||
| Size (A WG) |
Stranding | Insul Thick(Mils) |
Size (AWG) |
Stranding | Rated Strength (lbs.) |
inches | XLP | POLY | XLP | POLY | |
| AAC Neutral-messenger | |||||||||||
| Pateela | 6 | 7 | 45 | 6 | 7 | 563 | 14.88 | 103 | 103 | 85 | 70 |
| Oyster | 4 | 7 | 45 | 4 | 7 | 881 | 14.88 | 154 | 154 | 115 | 90 |
| Clam | 2 | 7 | 45 | 2 | 7 | 1350 | 20.58 | 233 | 233 | 150 | 120 |
| Murex | 1/0 | 7 | 60 | 1/0 | 7 | 1990 | 20.58 | 374 | 374 | 205 | 160 |
| Purpura | 1/0 | 9 | 60 | 1/0 | 7 | 1990 | 20.58 | 368 | 368 | 205 | 160 |
| Nassa | 2/0 | 7 | 60 | 2/0 | 7 | 2510 | 25.42 | 462 | 462 | 235 | 185 |
| Melita | 3/0 | 17 | 60 | 3/0 | 19 | 3310 | 29.97 | 562 | 562 | 275 | 215 |
| Portunus | 4/0 | 18 | 60 | 4/0 | 19 | 4020 | 29.97 | 696 | 696 | 315 | 245 |
| Nannynose | 336.4 | 19 | 60 | 336.4 | 19 | 6146 | 38.79 | 1118 | 1118 | 420 | 325 |
| *Code words for XLP insulated products are formed by adding "/XLP" to the conventional code words above (e.g.-Chihuahua/XLP) +Conductor temperature of 90 for XLP,75 for Poly;ambient temperature of 40;emissivity 0.2;2ft./sec.Wind in sun. | |||||||||||
