PVC Electrical Wire IEC Standard

Name: PVC Electrical Wire IEC Standard
Brand: HNTDDL
SKU: 132284193

Negotiable MOQ: 1 Kilometer (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Henan, China

Brand Name:

HNTDDL

Model Number:

PVC Insulation Wire

Henan Tong-Da Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name HNTDDL

Model Number PVC Insulation Wire

Insulation Material PVC

Type Low Voltage

Application Industrial

Conductor Material Copper

Specifications

We have attained ISO9001 & ISO14001 certificates.
we can produce against the customer's different requests.

PVC insulated electrical wire are covering series of wire products, its working voltage is 450/750V and its working temperature

is different according to different insulation materials, mainly 70 and 90 degrees temperature, etc.

According to the conductor type, including solid conductor PVC insulated electrical wire, standed PVC insulated wire,

Flexible PVC insulated wire with different colors.

According to its shape, including flat wire, round wire, etc. with different colors.

Accoding to its core number, including single core wire, multi-core wire, etc. with different colors.

Type	Name
BV	copper conductor pvc insulation electric wire
BLV	Aluminum conductor pvc insulation electric wire
BVR	copper conductor pvc insulation flexible electric wire
BVV	copper conductor pvc insulation pvc shealthed round electric wire
BVVR	copper conductor pvc insulation pvc shealthed parellel electric wire
BLVVR	Aluminum conductor pvc insulation pvc shealthed round electric wire

Type	Rated Voltage	Number Of Cores	Nominal Cross Section Of Conductor(mm2)
BV	450/750	1	0.75~400
BLV	450/750	1	1.5~400
BVR	450/750	1	0.75~400
BVV	450/750	1~5	0.75~35
BLVV	450/750	1~5	2.5~35
BVVB	450/750	2,3	0.75~6
BLVVB	450/750	2,3	0.75~6
RVS	300/500	2	0.3~6
RVV	300/500	2~10,12,14,16,19,24	0.3~6
RVVP	300/500	2~10,12,14,16,19,24	0.3~6
