Two Double Side Face Outdoor Full Color Led Display Screen
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Asram
Model Number:
P6mm dual faced led screen
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Good Shop Advertising P4/P7.62/P10/P20 Indoor/outdoor Large/small Double Side Led Display(two Faces)NegotiableMOQ: 1 Square Meter -
Led Light Advertising One/two Faces Indoor P4.75 Single Color Indoor Led Message Sign Board HotNegotiableMOQ: 1 Square Meter
-
Two Face or Double-sided Electronic Double Faces LED Advertising PanelNegotiableMOQ: 1 Square Meter
-
P6 Full Color Double Sided Video Advertising Led Sign, Indoor Two Face Led Display Panel Board Two Sided FacesNegotiableMOQ: 1 Square Meter
-
Two Face PH12 Double-sided Electronic Dual Face Outdoor Led Display PanelNegotiableMOQ: 1 Square Meter
Place of Origin
Guangdong, China
Brand Name
Asram
Model Number
P6mm dual faced led screen
Usage
Other, Indoor or semi-outdoor
Tube Chip Color
Other, Single color, dual color, full color
Display Function
Video
Pixels
Other, P4, P5, P6, P7.62, P8, P10, P12, P16, P20
Screen Dimension
customized
Specifications
Indoor video RGB led ad display signTwo dual-sided, double-faced
High resolution Brightness
Good visual effect
Low price
Hot sale product:
| Item No | P5 | P6 | P7.62 |
| Classification | Full color | Full color | Full color |
| Pixel pitch | 5mm | 6mm | 7.62mm |
| Size of module (mm) | 160*80 | 192*96 | 244*122 |
| Pixel density | 40000 dots/m2 | 27778 dots/m2 | 17222 dots/m2 |
| Pixel composition | 1R1G1B | 1R1G1B | 1R1G1B |
| LED encapsulation | SMD3528/5050 | SMD3528/5050 | SMD3528/5050 |
| Resolution of module | 32*16 | 32*16 | 32*16 |
| Power consumption | 25W | 25W | 25W |
| Best viewing distance | 2m | 4m | 6m |
| Best viewing angle (H) | 120° | 120° | 120° |
| Max power consumption | 1700 W/m2 | 1400 W/m2 | 1000 W/m2 |
| Size of standard cabinet(mm) | 640*480 | 768*576 | 976*732 |
| Resolution of standard cabinet | 128*96 | 128*96 | 128*96 |
| Weight of standard cabinet | 21kg | 30kg | 32kg |
| Driving IC (5026 optional) | MBI5024GF | MBI5024GF | MBI5024GF |
| Driving method | 1/8 constant | 1/8 constant | 1/8 constant |
| Frame frequency | more than60Hz/s | more than60Hz/s | more than60Hz/s |
| Refresh rate | more than360Hz/s | more than360Hz/s | more than360Hz/s |
| White balance brightness | more than3000cd/m2 | more than2500cd/m2 | more than2000cd/m2 |
| Work environment temperature | —20°C—50°C lower temperature is optional | ||
| Working voltage | 220±10% or 110±10% | ||
| Grey scale | Display colors more than 250M ( synchronized) | ||
| Brightness adjustment | 256 levels of each color (RGB) can be adjusted manually, and 8 levels of each color can be adjusted automatically | ||
| Signal input | RF,S-video, etc | ||
| Control system | PCTV non-linear editing card+ DVI display card+ main controller card+ optical fibre transmission ( optional) | ||
| MTBF | more than 5000 hours | ||
| Life span | more than100000 hours | ||
| Malfunction dot rate | less than0.0001 | ||
| Transmission distance | LAN cable less than100m; optic fiber transmission: MMF less than 500m, SMF less than 20km | ||
| Refresh rate can be higher by using more receivers: other parameter can be changed according to different application. | |||
Indoor SMD model: PH4, PH5, PH6, PH7.62, PH8, PH10, PH12, PH16, PH20, PH25, PH31.25, PH40.....
Outdoor DIP model: PH10, PH12, PH14, PH16, PH20, PH22, PH25, PH31.25, PH40, PH50, PH70......
Outdoor SMD model: PH6, PH8, PH10, PH12, PH14, PH16, PH18, PH20, PH25, PH31.25.....
Double faced(Two-sided): Single color, Dual color, Tri-color, Full color
We can customize any size according to your request.
OEM ODM service is acceptable
CE ROHS ISO certificate
